ULTIMATE OD6T-BRZ-T-EACH and ULTIMATE OD6T-PRIMED-EACH
Ultimate 6 in. 2-Way Outdoor Speaker, Ribbon Tweeter, Single
The Crestron® Ultimate speakers
ULTIMATE OD6T-PRIMED-EACH
pinnacle of performance for demanding outdoor installations. Select
materials, top shelf components, and a high-end appearance underscore
the design behind each speaker. The result is a no-compromise outdoor
speaker designed to be staked directly into the ground or mounted to an
exterior wall, fence post, or tree. The
speaker can be painted to blend with the surroundings.
In the Box
1 Ultimate 6 in. 2-Way Outdoor Speaker (6511868 or
6511869)
Additional Items
2 Wire nuts
ULTIMATE OD6T-BRZ-T-EACH
made by Origin Acoustics deliver the
ULTIMATE OD6T-PRIMED-EACH
and
Installation
Prepare the Site
The Crestron Ultimate speakers
ULTIMATE OD6T-PRIMED-EACH
stakes (not included). They can also be mounted to outdoor hard
surfaces, such as a trellis, under an eave, on a wall, on a deck, or to a
post using the surface/tree mounts (not included).
For in-ground level installation, choose a location that will not flood
l
and where the speaker will not be affected by an in-ground sprinkler
system.
For above-ground installation, mount the speaker with either the
l
surface or tree mounting bracket (not included).
Quick Start
ULTIMATE OD6T-BRZ-T-EACH
can be installed at ground level using
and
1
