- Page 1 Crestron SPK-6L Speaker Kit for Isys TPS-6L ® Wall Mount Touchpanel Installation Guide...
-
Page 2: Table Of Contents
Speaker Kit Contents Speaker Kit: SPK-6L Description... 1 Setup ... 2 Supplied Hardware ... 2 Installation ... 3 Resources... 6 Industry Compliance ... 6 Reference Documents... 6 Further Inquiries ... 7 Future Updates ... 7 Return and Warranty Policies ... 8 Merchandise Returns / Repair Service ... -
Page 3: Speaker Kit: Spk-6L
Refer to the latest version of the TPS-6L Operation & Installation Guide (Doc. 6556) for information on using the SPK-6L. The manual is available from the Crestron website (www.crestron.com/manuals). Installation Guide – DOC. 6625A Speaker Kit ®... -
Page 4: Setup
Speaker Kit Setup Supplied Hardware The SPK-6L Speaker Kit consists of three parts. These parts produce an assembly that attaches to the TPS-6L. Supplied Hardware of the SPK-6L DESCRIPTION Assy, Speaker Box, TPS-6L Cable Assy, Speaker Screws, 04-40 x 1/4, Phillips, Pan Head * Two extra screws are provided as spares. -
Page 5: Installation
1. Orient the speaker assembly as shown in the following illustration. Use a #2 Phillips screwdriver and attach the speaker to the rear of the touchpanel with four supplied screws. Attaching Speaker Installation Guide – DOC. 6625A Speaker Kit Speaker Kit: SPK-6L • 3... - Page 6 Then plug the six-wire cable from the speaker box assembly into the mating connector on the rear of the touchpanel. Connecting Cables 4 • Speaker Kit: SPK-6L Crestron SPK-6L Installation Guide – DOC. 6625A...
- Page 7 Crestron SPK-6L 3. Use a #2 Phillips screwdriver to secure the speaker box to the touchpanel with six supplied screws. Refer to the following illustration. Attaching Speaker Box Assembly Installation Guide – DOC. 6625A Speaker Kit Speaker Kit: SPK-6L • 5...
-
Page 8: Resources
Speaker Kit Resources Industry Compliance As of the date of manufacture, the SPK-6L has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. NOTE: This device complies with part 15 of the FCC rules. Operation is... -
Page 9: Reference Documents
Future Updates As Crestron improves functions, adds new features and extends the capabilities of the SPK-6L, additional information may be made available as manual updates. These updates are solely electronic and serve as intermediary supplements prior to the release of a complete technical documentation revision. -
Page 10: Return And Warranty Policies
All brand names, product names and trademarks are the sole property of their respective owners. Windows is a registered trademark of Microsoft Corporation. Windows95/98/Me/XP/Vista and WindowsNT/2000 are trademarks of Microsoft Corporation. 8 • Speaker Kit: SPK-6L Crestron SPK-6L Installation Guide – DOC. 6625A... - Page 11 Crestron SPK-6L Speaker Kit This page is intentionally left blank. Speaker Kit: SPK-6L • 9 Installation Guide – DOC. 6625A...
- Page 12 Crestron Electronics, Inc. Installation Guide – DOC. 6625A 15 Volvo Drive Rockleigh, NJ 07647 (2018883) Tel: 888.CRESTRON 11.07 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
