ULTIMATE IC3-SA-WOOFER/TWEETER-W-T-KIT
Ultimate 3 in. All Weather In-Ceiling Kit (Woofer and Tweeter)
The ULTIMATE IC3-SA-WOOFER/TWEETER-W-T-KIT
necessary components for a complete installation of the
ULTIMATE IC3-AW 2-way, new construction, all weather in-ceiling
speaker. Crestron® Ultimate in-ceiling speakers made by Origin
Acoustics® deliver the pinnacle of performance for demanding
residential installations.
In the Box
1 ULTIMATE IC3-AW-SA-BOX-WOOFER-W-T-EACH
woofer box
1 ULTIMATE IC3-AW-SA-TWEETER-EACH tweeter module
Additional Items
4 Spacers
3 Square grille trim rings
3 Round grille trim rings
1 Square grille
1 Round grille
includes the
The ULTIMATE IC3-SA-WOOFER/TWEETER-KIT is designed to be
mounted in between the joists of a new construction ceiling space
before the ceiling material is installed.
Connect the Speaker
The speaker cable connection from the amplifier to the speaker must be
made prior to mounting. To connect the speaker:
1. Run the speaker cable (not included) from the amplifier to the
speaker location, observing all appropriate local codes. Strip the ends
of the speaker cable approximately 0.25 in. to 0.50 in. (~6 mm to
~12 mm) and twist the strands.
2. Remove the included 2-pin terminal block from the woofer box. Insert
the positive lead of the speaker cable into the + terminal of the
terminal block, and insert the negative lead of the speaker cable into
the - terminal. Screw both terminal clamps into place using a flat
head screwdriver.
3. Insert the terminal block back into the woofer box.
Installation
Quick Start
1
