Takara Belmont Luxury MAXIM AB-9500P Operation Manual

Barber chair
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Takara Belmont Barber Chair
AB-9500P/E
Model No.
Operation Manual
Thank you for purchasing this Takara Belmont product.
Be sure to read this operation manual
before operating the chair and always
operate the chair properly according to
the instructions herein.
operation manual may lead to accidents. This product is
designed for commercial use in barber shops and beauty
salons. Do not use this chair for any applications other
than hairdressing/beauty-related procedures. Store this
operation manual in a secure location and refer to it
whenever necessary.
Use the "Book No." indicated on the back cover to request
another copy of this manual from Takara Belmont if it
becomes torn or damaged and unreadable, or is lost.
Failure to read this
Contents
1
6
7
7
7
8
10
10
12
14
15
17
19
20
21
21
22
23
24
25
26
28
29
29
29

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Luxury MAXIM AB-9500P and is the answer not in the manual?

Questions and answers

Related Manuals for Takara Belmont Luxury MAXIM AB-9500P

Summary of Contents for Takara Belmont Luxury MAXIM AB-9500P

  • Page 1: Table Of Contents

    Use the "Book No." indicated on the back cover to request another copy of this manual from Takara Belmont if it becomes torn or damaged and unreadable, or is lost.

  • Page 3: Safety Precautions (Must Be Obeyed)

    All these precautions describe important items related to safety. Be sure to always obey all the precautions contained in this manual. Takara Belmont has absolutely no responsibility for accidents that might be caused by failure to obey "Safety Precautions", "Use Precautions"...
  • Page 4 WARNING Power cords must be replaced by a certified technician Power cord replacement must be performed by the dealer, Takara Belmont staff, or a technician with equivalent certification. Consult an electrician for wiring work Wiring work must be performed by certified personnel. Consult an electrician for wiring work.
  • Page 5 Safety Precautions (Must be Obeyed) WARNING Precautions when changing the preset positions • Before and while setting the preset positions, thoroughly check that there are no bodies or limbs of persons, or possible obstacles in the operating range of the chair or the area around the chair. There is a danger of body parts being pinched by the chair, resulting in injury or damage.
  • Page 6 Also, stop using the chair, turn off the power, unplug the power plug, and contact your closest dealer or Takara Belmont. • Remove the power plug of a device from the outlet when not using it.
  • Page 7 Be constantly careful of and inspect for looseness, rattling, tilting, vibration, noise, odors and other possible problems. If you feel that something seems slightly different or not normal, immediately stop using the chair, and contact your closest dealer or Takara Belmont. Immediately wipe off any chemical solutions or water that spills on the chair Chemical solutions can become a stain, and their adhering to an electrical part can cause faulty operation or short circuit.

  • Page 8: Use Precautions

    The maximum load of this chair is 1,350 N (135 kgf/300 lbf). The raising speed of the seat declines as the maximum load is approached. Contact your closest dealer or Takara Belmont if the breaker function (p. 25) frequently operates. Be sure to keep a copy of the operation manual where these precautions are described.

  • Page 9: Locations Of Warning Labels

    Locations of Warning Labels Precautions Related to Synthetic (Natural) Leather ● Clothing dye adhering The color of clothing or belts can be transferred to the synthetic leather of this chair by means of contact. If color adheres to the leather, wipe off the stain as soon as possible by using a soft cloth that has been dabbed with a neutral detergent diluted with water to approximately 10% in order to prevent the stain from soaking in due to the plasticizer.

  • Page 10: Name Of Components

    Name of Components ■ Main Unit Backrest Armrest Service outlet (Models with the Seat C-type plug only) Right body Legrest Dryer/Iron holder (Roll-up type) AB-9500P Step Power plug Headrest Decorative end cap Backrest cover Pop-up cape holder Armrest molding Control panel Left body Legrest Pump cover...
  • Page 11 Name of Components ■ Operating Section Control panel C lamp (Lights up every time the chair is turned by 180° from the central position) Lit up: Central position Locked automatically a few seconds after the lamp lights up L lamp (Lights up when rotation is locked) Lit up: Rotation locked Flashing: Rotation enabled H lamp...

  • Page 12: Preparation

    Preparation Power Supply 1. Insert the power plug into the outlet C-type plug model • Be sure to fully insert the power plug into the outlet until reaching the Power plug base of the plug. Failure to fully insert the plug or a similar fault can result in a short circuit or heat generation that causes a fire.
  • Page 13 Preparation 2. Turn on the power Press the side with the mark to turn the power on. Press the side with the ◎ mark to turn the power off. Power switch <Power switch> OFF ( ◎ mark) ON ( mark)　 Power switch lamp *When the power is turned on with the chair rotation lock released, the chair rotation gets locked...

  • Page 14: How To Use

    How to Use (1) Guiding Customers 1. Rotate the chair so that the customer can be easily seated on the chair 1 Release the rotation lock Press the rotation lock switch to release the lock and enable rotation of the chair. (Operation is the same with the rotation lock switch on either side.) The chair lock switch is operated by a hydraulic system.
  • Page 15 How to Use 2. Using the cape holder Using the cape holder: • Provides space between the customer and the cutting cape to provide good ventilation. • Makes it easy to clean up the cut off hair. 1 Reach below the front of the cape holder, and gently push it upwards to eject it to the side.

  • Page 16: Raising/Lowering The Chair

    How to Use (2) Raising/Lowering the Chair 1. Raising the chair To raise the chair, step on the right side of the UP/DOWN pedal switch or press the UP/DOWN operation switch upwards. The chair operates while you are stepping on (pressing) the switch. UP/DOWN UP/DOWN pedal switch...

  • Page 17: Reclining/Raising The Backrest

    How to Use (3) Reclining/Raising the Backrest 1. Pulling out the headrest Do not use the headrest if it is not needed, such as for back shampooing. 1 Lift up the headrest operation lever Headrest rotation lock button and pull out the headrest. You can stop in any position.
  • Page 18 How to Use 3. Raising the legrest Push the legrest operation switch on the control panel (right or left) in the direction of the arrow to raise the legrest. Legrest operation switch Left Right Full-flat type Roll-up type The chair operates while the switch is pressed. 9500E 9500P *The roll-up type chair is equipped with a roll-up function that gradually extends the legrest forward as it is lifted.

  • Page 19: Using Preset Functions

    How to Use (4) Using Preset Functions 1. Using the preset function This function allows you to simply press the switch once to make the Preset Function ⇒ chair rise automatically to its preset position and the backrest recline. 1. Pull the headrest out to the desired position beforehand if you need to use it. 2.
  • Page 20 How to Use 2. Using the auto-return function Press the auto-return switch on the control panel (right or left). The chair height, backrest angle, legrest position, and seat position return to their original positions automatically. Auto-return switch Left Right Full-flat type Roll-up type 9500E 9500P...

  • Page 21: Adjusting The Seat

    How to Use (5) Adjusting the Seat This chair is equipped with a function that allows you to adjust only the seat section separately. Use this function to make the necessary adjustments. Right Left Setting the seat position for children Side view of the seat Seat position for children Push the seat operation switch on the control panel upwards.

  • Page 22: Using The Heater

    Be sure to turn off the heater switch when not necessary. • Turn off the power and remove the power plug if you feel abnormal heat when touching the legrest, and contact your closest dealer or Takara Belmont.

  • Page 23: Using The Service Set

    How to Use (7) Using the Service Set (Optional) Before starting work, insert the fixture side of the Armrest decorative end cap service table into the service table securing slot, Service table securing slot and push it all the way in. The table is now ready.

  • Page 24: Using The Service Outlets

    Immediately stop using the device, turn off WARNING the device power switch, and remove the power plug from the service outlet. Also, stop using the chair, turn off the power, unplug the power plug, and contact your closest dealer or Takara Belmont.

  • Page 25: Care And Maintenance

    Care and Maintenance Clean this chair after use to maintain it in a clean state. Leaving dirt or grime on the chair can result in the formation of mold. Always be sure to unplug the power plug from the outlet when cleaning the chair.

  • Page 26: Daily Inspection

    Care and Maintenance ■ Spray-type Hairstyling Products (Especially hard types) When using spray-type hairstyling products (especially hard types), check the entire chair to make sure that none of the product is adhering to the exterior surface of the chair (including leather parts).

  • Page 27: Before Requesting Repair

    If any of the problems described above are inspected and the chair does not work normally even after performing the recovery procedures, immediately stop using the chair, turn off the power, unplug the power plug, and contact your closest dealer or Takara Belmont.

  • Page 28: Daily Inspection Procedures

    If the alarm still sounds, the position detector might be faulty. Stop using the chair, turn off the power, unplug the power plug, and contact your closest dealer or Takara Belmont. □ □ Check that the chair moves Perform the procedures indicated in "(4)
  • Page 29 Stop from the chair. the chair. using the chair, turn off the power, unplug the power plug, and contact your closest dealer or Takara Belmont to inform of the abnormal situation. □ □ □...

  • Page 30: Specifications

    Specifications Model No. AB-9500P/E Rated voltage 230 V AC Rated frequency 50 Hz Rated current 2.0 A Weight 175 kg (385 lb) AB-9500P Maximum load 166 kg (365 lb) AB-9500E Operating noise volume 1,350 N (135 kgf/300 lbf) 70 dB or less Usage environment : Temperature  0 〜...

  • Page 31: Standard Period Of Use

    The length of the "standard period" differs depending on the use environment and frequency of use of the customer. For maintenance after the standard period of use, contact your closest dealer or Takara Belmont. Disposing of this Product Dispose of this chair and replaced parts in a proper manner that complies with local laws and regulations.
  • Page 32 EU REPRESENTATIVE MANUFACTURER TAKARA COMPANY EUROPE GmbH Berner Strasse 18, 60437 TAKARA BELMONT CORPORATION Frankfurt am Main, Germany 2-1-1, Higashishinsaibashi, Chuo-ku, Osaka, 542-0083, Japan Tel:+49 69 506878 0 TEL: 81-6-6212-3523 Fax:+49 69 506878 20 FAX: 81-6-6211-5745 Printed in Japan 2019-04 BOOK NO.AFFX64EE...

This manual is also suitable for:

Luxury maxim ab-9500e
