SALON CONSOLE
■ Salon Console
●Custom type
AY-CU*SX1 [single tap type]
AY-CU*SX2 [double tap type]
Operating Instructions
Thank you for purchasing this Takara Belmont product.
The instructions contained in this booklet should be
thoroughly read and understood before use.
Using this product before reading this operating manual
may result in an accident. This product is an industrial
shampoo unit designed for barbers and hair salons.
Only use this product for its intended purpose and do not
use it for non-hairdressing work.
Keep this manual and refer back to them when required.
Contents
Version 4
2017.05
2
2
5
8
8
8
9
9
10
14
15
20
20
20
20
21
21
21
22
23
24
26

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Salon Console and is the answer not in the manual?

Questions and answers

Related Manuals for Takara Belmont Salon Console

Summary of Contents for Takara Belmont Salon Console

  • Page 1: Table Of Contents

    Specifications Product Dimension Procedures for Daily Inspections MEMO Thank you for purchasing this Takara Belmont product. The instructions contained in this booklet should be thoroughly read and understood before use. Using this product before reading this operating manual may result in an accident. This product is an industrial shampoo unit designed for barbers and hair salons.

  • Page 2: Description Of Warning Symbols

    These precautions are important for ensuring safety. Adhere to these precautions at all times. Takara Belmont is not responsible for any damage or risk to the person using this product or those around them due to accidents if this product is used without adhering to the "Safety Precautions"...
  • Page 3 Warning Disassembly and Provide the service in correct repairs/modifications are prohibited. position. Disassembly Disassembly, repairs and modifications must not ● Be sure to install the combination chair to Prohibited be conducted by people except repair correct position. When the service is provided technicians.
  • Page 4 Caution Do not spray areas other than the Do not use this product if the plated surface is peeling. basin with water. Replace taps (the temperature control knob) if the ●Take care not to spray areas other than the basin peeling.

  • Page 5: Precautions For Use

    Caution Do not put fingers in the gap Do not use the product in a place between the basin and the where freezing is expected. basin box. Failure to follow this instruction may result in Do not put fingers in the gap between the basin breakage of parts, thus resulting in water and the basin box.
  • Page 6 Caution Do not touch the hot water pipe or Don’t splash the counter, the back mixing pipe. of operation panel and the side and back of basin box. The hot water pipe and mixing pipe become very hot. Do not touch them directly. Don’t splash the counter, the back of operation panel and the side and back of basin box.
  • Page 7 Caution Do not hook anything on the door If chemicals spill on to this product, handle of the side unit wipe them dry as soon as possible. Do not dangle or hook anything on the door If chemicals such as hair dyes spill on to this handle of the side unit.

  • Page 8: Position Of Warning Labels

    Position of Warning Labels Befor Using This Product ・Check the accessories are installed correctly to the product. ・Some surface of basin body, basin box and side unit is made of melamine. In some case, it can cause color unevenness or irregularity or foreign substances mixing. The process of making melamine results in them, so they are not defect or quality problem.

  • Page 9: Name Of Parts

    Name of Parts ［Double tap type］ Temparature control knob Shower head Shampoo bottle Bottle holder Handlebar Operation panel Counter Basin Inner panel ［Single tap type］ Tap (with adjusting temparature) Shower head Basin unit Shampoo bottle Bottle holder Maintenance door Operation panel Basin Inner panel Accessories...

  • Page 10: How To Use

    How to Use ■Open the basin box. (The picture below is double tap type) Hold the handlebar and pull the basin box open. Be sure to pull it open untill it stops. Handlebar ●Be sure to confirm safety before you pull the basin open and close. If you pull the basin open and close on customer’s fingers, they will be injured.
  • Page 11 ■Turn on hot water. / Turn off hot water. (The picture below is single tap type) 1. Hold the shower head carefully not to Blue mark (Cold) splash water for the customer. Turn on 2. Pull the tap up as this picture will put water out from the shower head.
  • Page 12 ■Adjusting the volume of water (The picture below is single tap type) 1. The volume of water will increase as the tap Blue mark is pulled up. (Cold) The maximum volume of water will be Increase output when the tap is pulled full up. Red mark (Hot) 2.
  • Page 13 ■Double tap type 1. Hold the shower head carefully not to Turn off splash the water to the customer. Cold Turn on 2. Turn the tap. 3. Turn the temperature control knob and adjust temperature. Temperature control knob Stop button ●To use hot water (40˚C or higher), turning the temperature control knob toward hot direction over the stop button more, it will make the water very hot.

  • Page 14: Guiding Customers

    Guiding Customers ■When shampooing (The picture below is double tap type) 1. Guide customer to sit on the chair. 2. Put a shampoo cloth on customer. Recommendation: shampoo cloth without dropper 3. Open the basin box. ( See the "How to Use" on page 10) Hold the handlebar and pull it open.

  • Page 15: Maintenance

    Maintenance Never use volatile chemicals such as thinners, alcohol, gasoline or kerosene, cleaning products such as wax with a scourer, a sponge with a scourer, detergents that include organic solvents, acidic, alkaline or chlorine-based detergents, or scouring pads. Failure to follow this instruction may cause scratches or discoloration.
  • Page 16 ■Basin box, Counter, Maintenance door, Side unit < How to care > Wipe off them with a soft or dry cloth. If they are extremely dirty, wipe with a 10% detergent solution diluted with the water. ● Don’t use a wire wool or sandpaper or metallic scourer. ●...
  • Page 17 ■ Around basin Open the basin and the maintenance door. Handlebar Basin Loosen the hose band and remove the drain hose. Drain hose Hose band Indication mark Pull the lever foward . Look position on the right side Lever Lock position Hold both ends of the basin.
  • Page 18 Clean the inside. Don’t splash the water for the back of Caution operation panel and scrub sealing forcedly. Operation panel Hold both ends of the basin and lift the front side of the basin slightly. Then place the edge of basin on the basin fixed link again.
  • Page 19 Drain hose Attach the drain hose. *Set the drain hose by indication mark. Hose band Then tighten the hose band. Indication mark Drain hose Elbow Indication mark Set the drain hose as the picture above by the indication mark. Pull the laver toward free position on the right side. Lever Free position Check that can pull the basin open and close smoothly.

  • Page 20: Daily Inspections

    Parts Replaced on a Regular Basis The following are parts that must be replaced on a regular basis as designated by Takara Belmont: □Drain hose: Replace every 3 years ・For the drain hose, there is a possibility that water leaks will occur because cracks are caused due to deterioration and hardening of the hose from chemical agents in the drain water.

  • Page 21: Before Requesting Repairs

    Before Requesting Repairs If the following problems arise, conduct the checks outlined before requesting repairs. Solution Symptom Check this Open the water stop valve ● There is no hot water Are the water stop valves in the pipe open? → ●...

  • Page 22: Specifications

    Specifications Basin body(Single tap type) P1-CU* Basin body(Double tap type) PT-CU* Product Side unit AY-W055R＊ AY-W064R＊ AY-W067R＊ Outside Dimensions See the "Product Dimensions" on page 23. Neck height 770 mm Mixing method Single tap type / Thermostat type Output method /output volume Shower outlet : 8 L/min (with hot water pressure...

  • Page 23: Product Dimension

    Dimensions Appearance Dimensions (Unit:mm) Custom type S size , L size ■Front view ■Side view W.L. ) shows the platform height of 150mm. Neck tip 719 S size 400 24 min. Base L size 500 22.5 F.L. Platform 380 Platform 1300 Platform 1200 S size 1200 , L size 1300 Custom type LL size...

  • Page 24: Procedures For Daily Inspections

    Procedures for Daily Inspections To ensure that this product can be used for a long period of time, conduct the inspections below. ■Inspect the product every day Inspection item Inspection method If the inspection results show defects □Can you pull the □When you pull the basin open and close, □It may cause malfunctions or deformed or basin open and...
  • Page 25 Inspection item Inspection method If the inspection results show defects □Does the basin  □Slowly push the front end of the □Rattle may cause incorrect operation or damage rattle? basin, in each direction and of the main body, or cause it to fall over. Stop check whether they rattle.

  • Page 26: Memo

    MEMO...
  • Page 27 MEMO...
  • Page 28 MEMO TAKARA BELMONT CORPORATION 1-1, 2-Chome, Higashi-shinsaibashi,Chuo-ku,Osaka,Japan : (06) 6212-3523 : (06) 6211-5745 Printed in Japan 1E02KHB0...
