Takara Belmont Barber Chair
L a n c e r
AB-HPPN AB-HPBN
Model No. :
Operation Manual
Takara Belmont would like to thank you for purchasing
Takara Belmont would like to thank you for purchasing
this Takara Belmont product.
Be sure to read this operation manual
before operating the chair and always
operate the chair properly according to
the instructions herein.
Failure to read this operation manual may lead to accidents.
This product is designed for commercial use in barber shops
and beauty salons.
Do not use this chair for any applications other than
hairdressing/beauty-related procedures.
Store this operation manual in a secure location and refer to
it whenever necessary.
Inform Takara Belmont of the book number on
the back cover to obtain a new operation manual
if this booklet becomes torn, damaged,unreadable,
or lost.
(The picture shows AB-HPPN)
and
Contents
6
7
7
8
10
13
18
19
19
22
23
23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LANCER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Takara Belmont LANCER

Summary of Contents for Takara Belmont LANCER

  • Page 1: Table Of Contents

    Daily Inspection Procedures Specifications Standard Period of Use (The picture shows AB-HPPN) Takara Belmont would like to thank you for purchasing Disposing of this Product Takara Belmont would like to thank you for purchasing this Takara Belmont product. Be sure to read this operation manual...

  • Page 3: Safety Precautions(Must Be Obeyed) 1 To

    All these precautions describe important items related to safety. Be sure to always obey all the precautions contained in this manual. Takara Belmont has absolutely no responsibility for accidents that might be caused by failure to obey "Safety Precautions", "Notes for Use" and "Notes Related to Synthetic (Natural) Leather" resulting in injury to users and other persons, or other damage.
  • Page 4 Sudden operation of the chair can result in injury. Installation precautions Installation of this chair must be performed by specialized personnel (personnel from Takara Belmont or Takara Belmont specified representative). The chair must be installed on a perfectly flat and solid floor.
  • Page 5 Safety Precautions (Must be Obeyed) WARNING Precautions when changing the preset positions Before and while setting the preset positions, thoroughly check that there are no bodies or limbs of persons, or possible obstacles in the operating range of the chair or the area around the chair. There is a danger of body parts being pinched by the chair, resulting in injury or damage.
  • Page 6 Safety Precautions (Must be Obeyed) WARNING Precautions during chair rotation Please rotate the chair after confirming that your customer is surely sitting. Confirm that there is no one around chair and be careful that the step etc. do not come in contact with the customers or equipment.
  • Page 7 Be constantly careful of and inspect for looseness, rattling, tilting, vibration, noise, odors and other possible problems. If you feel that something seems slightly different or not normal, immediately stop using the chair, unplug the power plug, and contact your closest dealer or Takara Belmont. Be extremely careful not to mistake the switches when operating.

  • Page 8: Notes For Use

    Safety Precautions (Must be Obeyed) CAUTION Be careful that the power supply code does not come in contact with the adjuster under the step. Be careful that the adjuster does not rub against the floor and does not catch on the power supply code when you rotate the chair for adjusting the adjuster.

  • Page 9: Locations Of Warning Labels

    Locations of Warning Labels Notes Related to Synthetic (Natural) Leather Clothing dye adhering The color of clothing or belts can be transferred to the synthetic leather of this chair by means of contact. If color adheres to the leather, wipe off the stain as soon as possible by using a soft cloth that has been dabbed with a neutral detergent diluted with water to approximately 10% in order to prevent the stain from soaking in due to the plasticizer.

  • Page 10: Accessories

    Accessories Operation manual (this manual) Installation manual Flange nut (M6) 3 pcs. Rubber ring Step (with adjuster) Name of Components Main Unit Headrest (with headrest cover) Backrest Armrest Cape holder Control panel Control panel cover Seat Legrest Synchronized movement type (AB-HPPN (PRIME TYPE)) Step...
  • Page 11 Name of Components Operating Section Control Panel Left Right (1) Rotation lock switch (2) Backrest switch These are collectively referred to as the (3) UP/DOWN switch "Control Panel". (4) Preset switch P1 (5) Preset switch P2 (6) Auto-return switch Foot Control Power switch (Breaker) Base Rotation lock switch...

  • Page 12: Preparation

    Preparation Power Supply 1. Insert the power plug into the outlet. Use an shared outlet with an attached ground terminal which is perfect for rated voltage and current of this production* outlet with an attached ground terminal.   Using the same outlet together with the Power cord power plug of other devices can result in abnormal heat generation and possible...

  • Page 13: How To Use

    How to Use (1) Guiding Customers 1. Rotate the chair so that the customer can be easily seated on the chair. 1 Release the base rotation with the rotation lock <Foot Control> switch. Pressing the rotation lock switch either at the foot control or the control panel releases the base rotation.
  • Page 14 How to Use 2. Using the cape holder Using the cape holder: Provides space between the customer and the cutting cape to provide good ventilation. Makes it easy to clean up the cut off hair. 1 Pull the cape holder located at the edge of the armrest outward, and rotate it forward.

  • Page 15: Raising/Lowering The Chair

    How to Use (2) Raising/Lowering the Chair 1. Raising the chair To raise the chair, step on the right side of the UP/DOWN foot switch at the foot control or press the UP/DOWN switch of the control panel (right or left) upwards. The chair is raised while stepping on (pressing) the switch.

  • Page 16: Reclining/Raising The Backrest 14 To

    How to Use (3) Reclining/Raising the Backrest 1. Pull out the headrest. Use the headrest when supporting the customer's head is needed, such as for shaving. Do not use the headrest if it is not needed, such as for back shampooing. 1 Put your hand in between the headrest and backrest to pull up the headrest.
  • Page 17 How to Use 2. Reclining the backrest Push the backrest switch of the control panel (right or left) in the direction of the arrow as shown in the below- left figure to recline the backrest. The backrest reclines while the switch is pressed. For the synchronized legrest type, the legrest is simultaneously raised when the backrest is reclined.

  • Page 18: Using Preset Functions 16 To

    How to Use (4) Using Preset Functions 1. Using the preset function A press of the preset switch moves the chair to the preset position. Two preset positions are available for this chair. 1 Pull the headrest out to the desired position previously if you need to use it. 2 Press the preset switch at the control panel (right or left) once.
  • Page 19 How to Use 2. Using the auto-return function Press the auto-return switch on the control panel (right or left) once. The chair height, backrest angle, and legrest angle (synchronized legrest type) return to their initial position for getting in/out of chair. (An electronic "pough" sound is emitted to notify you that operation is starting.) ⇒If the chair rotation lock is released, the chair rotation gets locked automatically when you press the auto-return switch.

  • Page 20: Care And Maintenance

    Care and Maintenance Clean this chair after use to maintain it in a clean state. Leaving dirt or grime on the chair can result in the formation of mold. Always be sure to unplug the power plug from the outlet when cleaning the chair. Cleaning of Each Part Leather Parts Plastic Parts...

  • Page 21: Daily Inspection

    If any of the problems described above are inspected and the chair does not work normally even after performing the recovery procedures, immediately stop using the chair, turn off the power, unplug the power plug, and contact your closest dealer or Takara Belmont.

  • Page 22: Daily Inspection Procedures 20 To

    Stop using the chair, turn off the power, unplug the power plug, and contact your closest dealer or Takara Belmont. Check that the chair raises Perform the procedures indicated in "(2) and lowers by using the Raising/Lowering the Chair"...
  • Page 23 Takara Belmont to inform of the abnormal situation. Check that no oil is Check that no oil has dripped Oil might be leaking from hydraulic parts.

  • Page 24: Specifications

    Specifications Model No. AB-HPPN (PRIME TYPE) AB-HPBN (BASIC TYPE) Weight 115 kg (254 lb) 112 kg (247 lb) Max. load 1350 N 1350 N (135 kgf/300 lbf) (135 kgf/300 lbf) Operating noise volume 70 dB or less 70 dB or less Usage environment Temperature 0 〜...

  • Page 25: Standard Period Of Use

    The length of the "standard period" differs depending on the use environment and frequency of use of the customer. For maintenance after the standard period of use, contact your closest dealer or Takara Belmont. Disposing of this Product Dispose of this chair and replaced parts in a proper manner that complies with local laws and regulations.
  • Page 26 NOTE...
  • Page 27 NOTE...
  • Page 28 NOTE TAKARA BELMONT CORPORATION 2-1-1, Higashishinsaibashi, Chuo-ku, Osaka, 542-0083, Japan TEL:81-6-6212-3523 FAX:81-6-6211-5745 Printed in Japan 1710 BOOK.No : 1E04K3DE Original instruction...
