Takara Belmont Barber Chair
L a n c e r
AB-HPPXN AB-HPBXN
Model No. :
Operation Manual
Takara Belmont would like to thank you for purchasing
this Takara Belmont product.
Be sure to read this operation manual
before operating the chair and always
operate the chair properly according to the
instructions herein.
Failure to read this operation manual may lead to accidents.
This product is designed for commercial use in barber
shops and beauty salons. Do not use this chair for any
applications other than hairdressing/beauty-related
procedures.
Store this operation manual in a secure location and refer to
it whenever necessary.
Please contact Takara Belmont if this operation manual
becomes torn or damaged and unreadable, or is lost.
(Picture shows the AB-HPPXN)
Contents
1
7
8
8
9
9 to 10
11
14
21
22
25
26
26

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lancer and is the answer not in the manual?

Questions and answers

Related Manuals for Takara Belmont Lancer

Summary of Contents for Takara Belmont Lancer

  • Page 1: Table Of Contents

    Speci cations Standard Period of Use (Picture shows the AB-HPPXN) Disposing of this Product Takara Belmont would like to thank you for purchasing this Takara Belmont product. Be sure to read this operation manual before operating the chair and always operate the chair properly according to the instructions herein.

  • Page 2: General Safety Instructions

    All these precautions describe important items related to safety. Be sure to always obey all the precautions contained in this manual. Takara Belmont has absolutely no responsibility for accidents that might be caused by failure to obey "Safety Precautions", "Notes for Use" and "Notes Related to Synthetic (Natural) Leather"...

  • Page 3: Safety Precautions (Must Be Obeyed) 2 To

    Sudden operation of the chair can result in injury. Installation precautions • nstallation of this chair must be performed by specialized personnel (personnel from Takara Belmont or Takara Belmont speci ed representative). • he chair must be installed on a perfectly at and solid oor.
  • Page 4 Safety Precautions (Must be Obeyed) WARNING Do not use in an environment where there are electromagnetic interference waves. sing this chair in an environment where there are electromagnetic interference waves can cause faulty operation. Do not install the chair near equipment that generates electromagnetic waves such as communication equipment and elevators.
  • Page 5 Safety Precautions (Must be Obeyed) WARNING Precautions during chair rotation e sure to always lock (secure) chair rotation by using the rotation lock switch after rotating the chair. Be especially careful of customer when the backrest is reclined. Check that the safety of the customer is ensured before rotating the chair.
  • Page 6 Takara Belmont. lways operate the power switch by your hands only. When the power switch is turned Turn off the power switch after...
  • Page 7 Safety Precautions (Must be Obeyed) CAUTION Precautions when using the cape holder • o not apply excessive force to the cape holder as it can only withstand a load of 10 N (1 kgf/2.2 lbf). • e sure to always return it to the stored state when not in use. •...

  • Page 8: Notes For Use

    NOTE Please contact your closest dealer or Takara Belmont if the breaker function (P.22) frequently operates. The maximum load of this chair is 1,350 N (135 kgf/298 lbf).　...

  • Page 9: Locations Of Warning Labels

    Locations of Warning Labels Notes Related to Synthetic (Natural) Leather lothing dye adhering  he color of clothing or belts can be transferred to the synthetic leather of this chair by means of contact. If color adheres to the leather, wipe off the stain as soon as possible by using a soft cloth that has been dabbed with a neutral detergent diluted with water to approximately 10% in order to prevent the stain from soaking in due to the plasticizer.

  • Page 10: Accessories

    Accessories • Operation manual (this manual) • Installation manual • Flange nut (M6) 3 pcs. • Rubber ring • Step (with adjuster) Name of Components ■Main Unit Headrest (with headrest cover) Backrest Armrest Cape holder Child seat Control panel Emergency rise switch Control panel cover Seat Legrest...
  • Page 11 Name of Components ■Operating Section Control Panel Left Right (1) Rotation lock switch (2) Backrest switch (3) UP/DOWN switch (4) Preset switch P1 These are collectively referred to as the "Control Panel". (5) Preset switch P2 (6) Auto-return switch (7) Child seat Up switch (8) Child seat Down switch Foot Control Power switch (Breaker)

  • Page 12: Preparation

    Preparation ■Power Supply 1. Insert the power plug into the outlet. • e sure to use a 120-V AC (7 A or more)* outlet for the power supply. Do not share use of the outlet with any other Power plug electrical device.

  • Page 13: How To Use

    How to Use (1) Guiding Customers 1. Rotate the chair so that the customer can be easily seated on the chair. 1 Release the base rotation with the rotation lock <Foot Control> switch. Pressing the rotation lock switch either at the foot control or the control panel releases the base rotation.
  • Page 14 How to Use 2. Using the cape holder Using the cape holder: Provides space between the customer and the cutting cape to provide good ventilation. Makes it easy to clean up the cut off hair. 1 Pull the cape holder located at the edge of the armrest outward, and rotate it forward. Pull out the cape holder outward by holding around the axis of the cape holder.

  • Page 15: Raising/Lowering The Chair

    How to Use (2) Raising/Lowering the Chair 1. Raising the chair 　To raise the chair, step on the right side of the UP/DOWN foot switch at the foot control or 　press the UP/DOWN switch of the control panel (right or left) upwards. 　The chair is raised while stepping on (pressing) the switch.

  • Page 16: Reclining/Raising The Backrest 15 To

    How to Use (3) Reclining/Raising the Backrest 1. Pull out the headrest. 　Use the headrest when supporting the customer's head is needed, such as for shaving. 　Do not use the headrest if it is not needed, such as for back shampooing. 1 Put your hand in between the headrest and backrest to pull up the headrest.
  • Page 17 How to Use 2. Reclining the backrest 　Push the backrest switch of the control panel (right or left) in the direction of the arrow as shown in the below-left 　 gure to recline the backrest. 　The backrest reclines while the switch is pressed. For the synchronized legrest type, the legrest is simultaneously 　raised when the backrest is reclined.

  • Page 18: Using The Child Seat Function 17 To

    How to Use (4) Using the Child Seat Function This chair is equipped with a child seat that is able to be individually raised and lowered. 1. Raising the child seat Press the child seat Up switch on the armrest control panel. The child seat will rise up while it is being pressed. ⇒If the chair rotation lock is released, the chair rotation gets locked automatically when you press the switch.
  • Page 19 How to Use ＜Emergency Rise Function＞ If an object or a body part such as a hand or leg is pinched between the child seat and the seat (shaded section of the following diagram) during child seat lowering, this function slightly raises the child seat and halts operation. When the system detects that an object or a body part has become pinched in the shaded area in the diagram, the child seat down switch is disabled.

  • Page 20: Using Preset Functions 19 To

    How to Use (4) Using Preset Functions 1. Using the preset function A press of the preset switch moves the chair to the preset position. Two preset positions are available for this chair. 1 Pull the headrest out to the desired position previously if you need to use it. 2 Press the preset switch at the control panel (right or left) once.
  • Page 21 How to Use 2. Using the auto-return function Press the auto-return switch on the control panel (right or left) once. The chair height, backrest angle, and legrest angle (synchronized legrest type) return to their initial position for getting in/out of chair. (An electronic "pough"...

  • Page 22: Care And Maintenance

    Care and Maintenance Clean this chair after use to maintain it in a clean state. Leaving dirt or grime on the chair can result in the formation of mold. Always be sure to unplug the power plug from the outlet when cleaning the chair. ■Cleaning of Each Part Leather Parts Plastic Parts...

  • Page 23: Daily Inspection

    Daily Inspection Perform inspection according to the "Daily Inspection Procedures" indicated on pages 23 and 24 of this operation manual in order to ensure safe use of this chair. erform daily inspection according to the "Daily Inspection Procedures". Using the chair without performing daily inspection can result in malfunction or accident.

  • Page 24: Daily Inspection Procedures 23 To

    If any of the problems described above are inspected and the chair does not work normally even after performing the recovery procedures, immediately stop using the chair, turn off the power, unplug the power plug, and contact your closest dealer or Takara Belmont. Daily Inspection Procedures Perform the following inspection procedures in order to ensure that the chair can be used safely.
  • Page 25 　Stop using the chair, turn off the power, unplug the power plug, and contact your closest dealer or Takara Belmont to inform of the abnormal situation. □Check that no oil is □Check that no oil has dripped □Oil might be leaking from hydraulic parts.

  • Page 26: Speci Cations

    Speci cations Model No. AB-HPPXN AB-HPBXN Weight 120 kg (265 lb) 117 kg (258 lb) Max. load 1,350 N (135 kgf/298 lbf) (When child seat in use: 500 N (50 kgf/110 lbf)) Operating noise volume 70 dB or less Rated voltage 240 V AC 230 V AC 220 V AC...

  • Page 27: Standard Period Of Use

    (including parts replacement). This is not a warranty period. The length of the "standard period" differs depending on the use environment and frequency of use of the customer. For maintenance after the standard period of use, contact your closest dealer or Takara Belmont. Disposing of this Product...
  • Page 28 TAKARA BELMONT CORPORATION 1-1, Higashi-shinsaibashi 2-Chome,Chuo-ku,Osaka,Japan TEL:(06)6213-5945 FAX:(06)6212-3680 1E04LDA0 Printed in Japan 1504 Original instruction...
