Takara Belmont Barber Chair
AB-LGS
Model No.
AB-LGP
AB-LGSX AB-LGLX
Operation Manual
Takara Belmont would like to thank you
for purchasing this Takara Belmont
product.
Be sure to read this operation manual
before operating the chair and always
operate the chair properly according to the
instructions herein.
Failure to read this operation manual may
lead to accidents.
This product is designed for commercial
use in barber shops and beauty salons.
Do not use this chair for any applications
other than hairdressing/beauty-related
procedures.
Store this operation manual in a secure
location and refer to it whenever necessary.
Please inform Takara Belmont of the book
number on the back cover to obtain a new
operation manual if this operation manual
becomes torn or damaged and unreadable, or is
lost.
AB-LGL
AB-LGF
Contents
(4) Using Sheat arange mode
1
7
8
8
8
9
11
11
13
15
16
20
23
25
26
26
27
28
28
29
30
31
33
36
37
37
37
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Takara Belmont LEGEND
Summary of Contents for Takara Belmont LEGEND
-
Page 1: Table Of Contents
(7) Heater (AB-LGP,LGF) (8) Accumulator (9) Dryer/Iron Holder (10) Service Outlets (Type C Specification) (11) Foot Cushion Takara Belmont would like to thank you for purchasing this Takara Belmont CARE AND MAINTENANCE product. DAILY INSPECTION Be sure to read this operation manual... -
Page 2: Safety Precautions (Must Be Obeyed)
All these precautions describe important items related to safety. Be sure to always obey all the precautions contained in this manual. Takara Belmont has absolutely no responsibility for accidents that might be caused by failure to obey "Safety Precautions" and "Notes for Use" resulting in injury to users and other persons, or other damage. - Page 3 SAFETY PRECAUTIONS (MUST BE OBEYED) WARNING Power cord replacement must be performed by a certified person. Power cord replacement must be performed by your closest dealer, Takara Belmont or a technician with equivalent certification. Consult an electrician for wiring work.
- Page 4 SAFETY PRECAUTIONS (MUST BE OBEYED) WARNING Precautions for the surrounding area during chair operation Before and during operation, thoroughly check that there are no bodies or limbs of persons, or possible obstacles in the operating range of the chair (ranges of seat raising/lowering, backrest reclining/raising, chair rotation, legrest operation) or nearby.
- Page 5 SAFETY PRECAUTIONS (MUST BE OBEYED) WARNING Precautions during chair rotation • When rotating the chair with a customer seated, always make sure that the customer is seated completely before rotating the chair. • Always be sure that no other persons are in the surrounding area before rotating the chair, and rotate so that the step and other parts do not contact the customer or any nearby equipment.
- Page 6 If you feel that something seems slightly different or not normal, immediately stop using the chair, and contact your closest dealer or Takara Belmont. Immediately wipe off any chemical solutions or water that spills on the chair.
- Page 7 SAFETY PRECAUTIONS (MUST BE OBEYED) CAUTION Precautions for using Dryer/Iron Holder • Be careful that the dryer or iron does not contact the legs or other body parts of the customer when using the dryer/iron holder. • Always be sure to store the holder under the body after use so it does not interfere with work.
-
Page 8: Notes For Use
The maximum load of this chair is 1,350 N (135 kgf/300 lbf ). The raising speed of the seat declines as the maximum load is approached. Contact your closest dealer or Takara Belmont if the breaker function (P. 31) frequently operates. -
Page 9: Locations Of Warning Labels
LOCATIONS OF WARNING LABELS NOTES RELATED TO SYNTHETIC (NATURAL) LEATHER ● Clothing dye adhering The color of clothing or belts can be transferred to the synthetic leather of this chair by means of contact. If color adheres to the leather, wipe off the stain as soon as possible by using a soft cloth that has been dabbed with a neutral detergent diluted with water to approximately 10% in order to prevent the stain from soaking in due to the plasticizer. -
Page 10: Name Of Components
NAME OF COMPONENTS ■ Main Unit Headrest cover (Leather) Backrest Cape holder Armrest Control panel (Left) Armrest end Service outlet decoration ※The presence or absence of the service outlet may differ Seat depending on the region of the use. Body cover (Left) Legrest Base Rubber ring... - Page 11 NAME OF COMPONENTS ■ Operating Section Control Panel Left Right (5) (6)(3) (2) (1) Backrest switch (5) Preset switch P1 (2) UP/DOWN switch (6) Preset switch P2 (3) Legrest switch (7) Legrest heater switch(AB-LGP,LGF) (4) Auto-return switch Sheat arange mode swith(AB-LGSX,LGLX) (8) Service outlet ※There is service outlet Type C Specification.
-
Page 12: Preparation
• Power cord replacement must be Ground performed by your closest dealer, Takara Belmont or a technician with Power plug equivalent certification. • Use an unshared * outlet with an attached ground terminal. - Page 13 PREPARATION 2. Turn on the power. Press the side with the mark to turn the power on. Press the side with the mark to turn the power off. Power switch OFF ( mark) ON ( mark) <Power switch> Turn off the power switch and remove the power plug from the outlet when the chair is not in WARNING...
-
Page 14: How To Use
HOW TO USE (1) Guiding Customers 1. Rotate the chair so that the customer can be easily seated on the chair. 1 Release the base rotation with the rotation lock switch. Pressing the rotation lock switch either at the foot control or the control panel releases the base rotation. - Page 15 HOW TO USE 2. Using the cape holder Using the cape holder: • Provides space between the customer and the cutting cape to provide good ventilation. • Makes it easy to clean up the cut off hair. Armrest 1 Pull out the front part of the cape holder to the side. Cape holder 2 Rotate the pulled-out cape holder forward.
-
Page 16: Raising/Lowering The Chair
HOW TO USE (2) Raising/Lowering the Chair 1. Raising the chair To raise the chair, step on the right side of the UP/DOWN foot switch on the foot control or press the UP/DOWN switch of the control panel upwards. The chair operates while the stepping on (pressing) the switch. UP/DOWN foot switch UP/DOWN switch (Up switch) -
Page 17: Reclining/Raising The Backrest
HOW TO USE (3) Reclining/Raising the Backrest 1. Pull out the headrest. Use the headrest when supporting the customer's head is needed, such as for shaving. Normal Headrest (AB-LGS,LGSX) Lift up the headrest storage lever and pull up the headrest. １ ... - Page 18 HOW TO USE Lift up Headrest (AB-LGL,LGLX,LGP,LGF) 1 Lift up the headrest storage lever and pull up the headrest. Secure the headrest at the desired position so that you can use it at that position. If the headrest is excessively pulled out, return it while pressing the headrest operation button. Headrest When pulling out the stored Headrest...
- Page 19 HOW TO USE Remove or Install the headrest. When the headrest is not used, the headrest inner pipe can be removed from the chair. To install the Inner pipe pipe, insert the inner pipe into the lock supporting rod while pressing the headrest storage button (or headrest operation button) and aligning with the Guide guide.
- Page 20 HOW TO USE 2. Reclining the backrest Push the backrest switch of the control panel in the direction of the arrow to recline the backrest. The chair operates while the switch is pressed. Backrest switch Left Right If any switch except for the legrest heater switch,seat arange mode switch is pressed while the chair rotation lock is released, chair rotation is engaged and then locked.
-
Page 21: (Ab-Lgsx,Lglx)
HOW TO USE 4. Lowering the legrest Push the legrest switch of the control panel in the direction of the arrow to lower the legrest. The chair operates while the switch is pressed.(AB-LGF:synchronized with the step.) Legrest switch Left Right If any switch except for the legrest heater switch,seat arange mode switch is pressed while the chair rotation lock is released, chair rotation is engaged and then locked. - Page 22 HOW TO USE (4) Using seat arange(AB-LGSX,LGLX) This chair is equipped with a function that allows you to adjust only the seat section separately. Use this function to make the necessary adjustments. Pash the seat arange mode switch SEAT ①Press the seat arange mode switch of the ②Auto-return swtich is Flashing.
- Page 23 HOW TO USE Side view of the seat Setting the front shampooing position Push the UP/DOWN switch on the control panel upwards. The seat continues to rise Front shampoo position as long as you hold the switch. The front part of the seat tilts forward, allowing you to set the chair to the best position to provide treatment during front shampooing.
-
Page 24: Using Preset Functions
HOW TO USE (5) Using Preset Functions 1. Using the preset function A press of the preset switch moves the chair to the preset What is the preset function? ⇒ position. You can set up to two optional positions of this chair. - Page 25 HOW TO USE 2. Using the auto-return function Press the auto-return switch on the control panel once. The chair height, backrest angle and legrest position return to their initial position (position for getting in/out of chair). (For safety reasons, an electronic "pough" sound is emitted when operation starts.) Auto-return switch Left Right...
-
Page 26: Removable Step
HOW TO USE (6) Removable Step You can remove the step anytime it might interfere such as when sitting a wheelchair customer in the chair. (AB-LGS,LGSX,LGL,LGLX,LGP) Legrest plating Step (underside) Hexagonal Loosen Guide Tighten nut (M10) for adjuster Positioning Extend Adjuster stoppers Retract... -
Page 27: Heater(Ab-Lgp,Lgf)
HOW TO USE (7) Heater(AB-LGP,LGF) The legrest heater is available on the customer's request. 1 Operating the heater Left Legrest heater switch Press the legrest heater switch (indicated as "HEATER") on the control panel (chair left side) to HEATER operate the heater. (Heater light turns on.) 2 Stopping the heater Press the legrest heater switch again to stop heater operation. -
Page 28: Dryer/Iron Holder
HOW TO USE (9) Dryer/Iron Holder Pull out the dryer/iron holder under the body on the right side of the chair. You can use this as a stand for a hand dryer or iron while working. Iron slots Dryer/iron holder Dryer slot •... -
Page 29: Service Outlets (Type C Specification)
HOW TO USE (10) Service Outlets (Type C Specification) Total (right and left sides) electricity available for use is Service outlet 230V AC / 7 A or less when not operating the chair, and 4 A or less for service outlets (right and left sides) when operating the chair. -
Page 30: Care And Maintenance
CARE AND MAINTENANCE Clean this chair after use to maintain it in a clean state. Leaving dirt or grime on the chair can result in the formation of mold. Always be sure to unplug the power plug from the outlet when cleaning the chair. ■... -
Page 31: Daily Inspection
CARE AND MAINTENANCE ■ Spray-type Hairstyling Products (Especially hard types) When using spray-type hairstyling products (especially hard types), check the entire chair to make sure that none of the product is adhering to the exterior surface of the chair (including leather parts). Immediately wipe off any hairstyling product that is adhering to the chair. -
Page 32: Before Requesting Repair
If the power cannot be service outlet? turned on when using a different device, contact your closest dealer Might there or Takara Belmont. be a short circuit? Breaker Function This is a protective function that prevents damage to devices due to using a current that exceeds the 7A... - Page 33 If any of the problems described above are inspected and the chair does not work normally even after performing the recovery procedures, immediately stop using the chair, turn off the power, unplug the power plug, and contact your closest dealer or Takara Belmont.
-
Page 34: Daily Inspection Procedures
Stop using the chair, turn off the power, unplug the power plug, and contact your closest dealer or Takara Belmont. □ □ Check that, approximately Check that none of the operating five seconds after turning switches are pressed. - Page 35 Takara Belmont. □ □ Check that the chair Perform the procedures indicated in legrest can be raised and "(3) Reclining/Raising the Backrest"...
- Page 36 Stop using the chair, turn off chair. chair. the power, unplug the power plug, and contact your closest dealer or Takara Belmont to inform of the abnormal situation. □ □ □ Check that no oil is...
-
Page 37: Specifications
SPECIFICATIONS Model No. AB-LGS/AB-LGSX/AB-LGL/AB-LGLX/AB-LGP/AB-LGF Rated voltage 230 V AC Rated frequency 50/60 Hz Rated current 2.0 A AB-LGS, LGSX,LGL,LGLX 2.2 A AB-LGP, LGF Weight 135 kg (298 lb) AB-LGS, LGL, LGP 130 kg (286 lb) AB-LGF 144 kg (317 lb) AB-LGSX,LGLX Max. -
Page 38: Standard Period Of Use
The length of the "standard period" differs depending on the use environment and frequency of use of the customer. For maintenance after the standard period of use, contact your closest dealer or Takara Belmont. DISPOSING OF THIS PRODUCT Dispose of this chair and replaced parts in a proper manner that complies with local laws and regulations. - Page 39 NOTE...
- Page 40 MANUFACTURER EU REPRESENTATIVE TAKARA COMPANY EUROPE GmbH Berner Strasse 18, 60437 Frankfurt am Main, Germany TAKARA BELMONT CORPORATION Tel:+49 69 506878 0 2-1-1, Higashishinsaibashi, Chuo-ku, Fax:+49 69 506878 20 Osaka, 542-0083, Japan TEL:81-6-6212-3523 FAX:81-6-6211-5745 Printed in Japan 2019-01 BOOK NO. 1E051MEE...
