- Page 1 MAX POWER ∫ A copy of this manual must remain on board for consultation. Last update: December 2013 INSTALLATION MANUAL RETRACT R 450...
-
Page 2: Installation Procedures
MAX POWER INTRODUCTION CONTACTING MAX POWER IMPORTANT GENERAL INFORMATION CHECK LIST FOR THE PROJECT MANAGER DETERMINING BEST EQUIPMENT LOCATION OF THE RETRACT THRUSTER UNIT OF THE AUXILIARY EQUIPMENT INSTALLATION PROCEDURES CONSTRUCTION OF THE MOUNTING BASE CONSTRUCTION OF HULL OPENING & CLOSING PLATE... -
Page 3: Important General Information
MAX POWER INTRODUCTION AFTER SALES SERVICE ADDRESS : MAX POWER Via Philips 5, 20900 Monza, Italy TEL : + 39 039 200 1973-936 FAX : + 39 039 2004299 RETRACT SERIAL N° . R4 _ _ . _ . _ _... - Page 4 IMPORTANT : All Test readings must be filled out on the form provided and sent to Max Power by fax no later than one week after the water tests have been completed so that the Max Power standard warranty is correctly validated. This form is attached at the end of this manual.
-
Page 5: Guide Blocks
INSTALLATION OF THE RETRACT UNIT CONSTRUCTION OF THE MOUNTING BASE MAX POWER can supply as an option, a G.R.P. laminated mounting base, aluminium alloy machined mounting-flange. These options allow you to save considerable installation time, and assure precise installation. -
Page 6: Construction Of Hull Opening & Closing Plate
MAX POWER METAL HULLS: The mounting base may be constructed with the hull or prefabricated, and then welded onto the hull later. IMPORTANT: In both cases, the top surface of the mounting base ( the flange) must be given particular attention and machined perfectly flat in order to accept the « O »... - Page 7 The nylon washers avoid stainless steel contact with the aluminium case. The nuts should be NYLOCK self-locking type. The 4 lifting lugs provided by MAX POWER, should be put in a small plastic bag, along with the hydraulic pipe plugs, for storage and future use by the ships crew .
- Page 8 MAX POWER It may be necessary to readjust the slide bar height so that the Bar engages automatically or so that the bar is not loose when the thruster closes. This is done as follows Loosen the two bolts holding the locking slide guide (F on drawing N°4) and adjust its height by using 19 mm bolt (G).
- Page 9 All the hydraulic power equipment, such as the piping, reservoir, pump, directional valve, etc. should be installed in compliance with the usual rules of accessibility to enable periodic checks and maintenance. MAX POWER recommends the use of ISO GRADE 15 to 32 hydraulic oils for the power circuit. PRESSURE PIPING...
-
Page 10: Directional Control Valve
The control box command’s the up down unit and hydraulic power spool valves in the correct sequence with correct timing. (Sequence chart with diagrams) There is scope for modifying sequence timing in this box but consult MAX POWER FIRST! (See diagram N° 8) All Retract equipment is connected to this box (See diagram N°... -
Page 11: After Launching
MAX POWER recommends the use of ISO GRADE 15 to 32 hydraulic oils for the power circuit. This mineral oil has already been used by Max Power during the run in tests and consequently the RETRACT motor and piping are already filled with this kind off oil. -
Page 12: Operation And Use
MAX POWER Warning: All hydraulic systems develop very high pressures. Failure of piping, connections etc that have been improperly installed will most likely happen on start up. Stay clear of these components. Wear eye protection, and be aware that high- pressure oil can cause major skin damage. -
Page 13: Troubleshooting Guide
15 min at 20°C Continuous operation: 5 min at 20°C For longer service periods, Max Power recommends an optional heat exchanger and water pump installation to provide extra oil cooling. TROUBLESHOOTING GUIDE PROBLEM : Thrust stops almost immediately after it has been applied. The alarm buzzer comes on and the green light turns off. - Page 14 MAX POWER The RETRACT 440 is equipped with a manual override device which can be used for lowering the RETRACT turbine from the UP to the DOWN position. IMPORTANT never leave the Manuel override screw unscrewed while using the hydraulic up down unit this would result in very serious damage.
- Page 15 MAX POWER 8. Check the entire hydraulic system hoses and connections for possible chaffing and leaks. 9. Every two years, drain the entire hydraulic oil system. Clean and replace filters. 5 YEARS Complete removal of unit and return to factory.
- Page 16 MAX POWER PROJECT MANAGER’S TEST RESULTS FORM To be filled out and faxed to MAX POWER - 16 INSTALLATION MANUAL RETRACT R 450...
-
Page 17: Max Power
MAX POWER TEST RESULT FORM (part 1) This form must be filled out and faxed to MAX POWER within a week after launching From : so that the MAX POWER standard warranty is validated. ……………………………… ……………………………… ……………………………… MAX POWER ………………………………... - Page 18 MAX POWER When all the tests have been completed as per the manual, please record the following measurements where applicable. With the engine(s) running, thruster in the down position, but not running: Record the voltage at the remote control box: …………………...
- Page 19 MAX POWER As long as possible Turning center - 19 INSTALLATION MANUAL RETRACT R 450...
- Page 20 MAX POWER Mounting base as supied by MAX POWER Hull parts manufactured by ship yard Principal dimentions Optional flotation foam to reduce loss of boyancy Retract Thruster Construction point ( Never changes nomater the hull shape ) Flexable water seals...
- Page 21 MAX POWER Thruster mounted to high Will cause low performance and more loss of boyancy. Thruster mounted corectly Thruster mounted to low Will cause contact between Hull plate and thrusters turbine. This will seriously damage turbine. - 21 INSTALLATION MANUAL RETRACT R 450...
- Page 22 MAX POWER Closing adjustments (lock) This is a correctly locked thruster Maximum gap 0.01mm Closing adjustments (closing plate) Fig 1 Caution this situation would cause damage to the turbine while at sea . In this situation there is still up wards movement possible...
- Page 23 MAX POWER - 23 INSTALLATION MANUAL RETRACT R 450...
- Page 24 MAX POWER Manuel operation To use manual lowering screw Disconnect hydraulic connections on ram A&B(or energise up down unit control valve) Turn manual lowering screw clockwise Place security bolt (A) in thread hole (B) before working on the unit. When finished reverse operation making sure that when raising the unit the thruster follows the up motion progressively.
- Page 25 MAX POWER - 25 INSTALLATION MANUAL RETRACT R 450...
- Page 26 MAX POWER POWER 47nk400 47nk400 47nk400 47nk400 47nk400 47nk400 47nk400 47nk400 47nk400 47nk400 47nk400 Switch bar C10 The more bars are on the longer the time delay before port 31&32 energisie 47nk400 47nk400 47nk400 47nk400 47nk400 12 13 14 15 16 17 18 19...
- Page 27 MAX POWER - + + + + + + + + + - + + + + 2 12 13 14 15 16 17 18 19 10 11 Plan for custom panel - + + + + + + + + + - +...
- Page 28 MAX POWER Standard panel The red turn button illuminates when the thruster is up and locked . The green light illuminates when the thruster is down and ready to function . POWER Pushing the joy stick up Turning the switch to the Turning the switch to the raises the thruster .
