- Page 1 Instructions for use. momo motion. The tried-and-tested tricycle with E-drive.
- Page 2 Instructions for use may deviate from your product due to differing equipment. We reserve the right to make technical modifications. Important information! Ensure that these Instructions for use remain with the product. Your schuchmann Team...
-
Page 3: Table Of Contents
2. Product description. Contents. 1. Preparation................. 06 1.1 Delivery ..........................06 1.2 Safety measures prior to use ................06 1.3 Safe disposal .......................06 1.3.1 Packaging ......................06 1.3.2 Product ........................06 1.4 Where to store the Instructions for use ............06 2. Product description..............07 2.1 General information .................... - Page 4 Contents. 3.3.5 Charge status display .................27 3.3.6 Functions ......................27 3.3.7 Deleting counter readings ................ 29 3.3.8 Brightness switching ..................29 3.3.9 Switching the lighting on and off............30 3.3.10 Registering a PIN ..................30 4. Settings..................31 4.1 Presets ..........................31 4.1.1 Handlebar adjustment..................
- Page 5 Contents. 6.2 Servicing / controls ....................45 6.3 Maintenance ......................46 6.3.1 Maintenance specifications ..............46 6.3.2 Maintenance plan ..................47 6.4 Repairs ...........................48 6.5 Controls ......................... 49 6.6 Storage .......................... 49 6.7 Spare parts ........................49 6.8 Duration of use and re-use ................. 49 6.9 Error messages and troubleshooting .............50 7.
-
Page 6: Preparation
1. Preparation. 1. Preparation. 1.1 Delivery On receiving the product, please check it for completeness, lack of faults and any transport damage. Inspect the goods in the presence of your forwarder. Should transport damage have occurred, please arrange for an inventory (determination of the faults) to be made in the presence of the forwarder. -
Page 7: Product Description
PU (polyurethane). 2.2 Handling and transport The momo motion. is not designed to be carried, as it is fitted with tyres. Should you have to carry the equipment due to obstacles, ensure that all moving parts are tightened. -
Page 8: Contraindications
2. Product description. the muscles with simultaneous function preservation). The mobility of the joints is supported and the restrictions are counteracted by insufficient cardio-respiratory function of the patients. The function of residual power support is hereby emphasised. 2.3.2 Contraindications In general, the indication should be accompanied by a doctor/orthopae- dist. -
Page 9: Equipment In Accordance With Stvzo
• The tricycle must be stored out of the reach of users who cannot assess the risks involved. 2.5 Equipment in accordance with StVZO The momo motion. corresponds with the requirements in accordance with StVZO and is equipped as follows: • Two brakes functioning independently of one another •... -
Page 10: Riding Response
2. Product description. 2.6 Riding response The momo motion. has a different riding response compared to conventional bicycles and tricycles without electric assistance. We therefore recom- mend initially becoming familiar with the momo motion. off public roads without assistance from the electric drive. When using the electric drive, please start with the lowest assistance level to gain confidence in using the tricycle. -
Page 11: Before Each Journey
The tricycle should be taken to your specialist dealer every 1000 km, but at least once a year for inspection. 2.6.2 Riding with and without E-drive The momo motion. can be used both with and without the assistance of the electric drive. Operating instructions The momo motion. -
Page 12: Range
2. Product description. 2.6.3 Range The range of the momo motion. depending on the following factors: • Course (gradients) • Load/rider weight • Selected assistance level • Riding style. The manufacturer of the drive system, HEINZMANN, estimates a range of 40 to 80 km per battery pack charge. -
Page 13: Product Overview
2.8.1 Pennant The pennant shown above is for better visibility of the momo motion. and therefore obviously also of the user. The pennant together with the plastic rod (about 160 cm long) is attached to the rear axle. -
Page 14: Overview Of Equipment / Accessories
DirectPower E-drive from Heinzmann The new momo motion. is equipped with the DirectPower E-drive from Heinzmann. This allows us to offer you a wear-free and silent direct drive. The motor is designed to be brushless and without gears. This minimises maintenance and wear and eliminates motor noise. - Page 15 2. Product description. Saddles Art. No. Saddle Width Length 37 01 001 Standard saddle Size 1 15 cm 21 cm 37 02 001 Standard saddle Size 2 15 cm 24 cm 37 03 001 Standard saddle Size 3 18 cm 26 cm Art.
- Page 16 2. Product description. Headrest Art. No. Headrest Width Height 37 01 029 Headrest Size 1 20 cm 15 cm 37 02 029 Headrest Size 2 23 cm 18 cm Handlebars Art. No. Classic handlebars – black Width 37 02 011 Classic handlebars for 16"...
- Page 17 2. Product description. Foot pans Foot pans Min. Max. Min. Max. Min. Max. with dy- height of height Art. No. width width width width Length namic leg leg gui- Leg gui- at front at front at rear at rear guidance dance dance 37 01 035...
- Page 18 2. Product description. Positioning Art. No. Chest strap – for the width adjustable back pelotte pad Width Length 37 01 050 Chest strap Size 1 5 cm 18.5 cm 37 02 050 Chest strap Size 2 6.5 cm 25.5 cm 37 03 050 Chest strap Size 3 7 cm...
-
Page 19: Drive Possibilities
2. Product description. 2.10 Drive possibilities The momo motion. can be equipped with the following drives: Freewheel brake hub (with backpedal brake) The freewheel brake hub allows the user to stop and start pedaling as they wish. They can brake by pedaling backwards. -
Page 20: E-Drive
3. E-drive. 3.1 Components 3.1.1 Motor The momo motion. is equipped with a rushless electric motor (A) as a power source. This provides both a strong tor- que in continuous operation as well as considerable peak torques (for example when starting). Mechanical losses are negligible because the motor is desi- gned without a gearbox. -
Page 21: Lithium Ion Battery Pack
3. E-drive. 3.2 Lithium ion battery pack The battery pack pack is very light, but with very high charging capacity. Proper charging and protection against deep discharge and overheating will significantly increase the service life. A corresponding charge controller, which takes into account all these require- ments, is therefore already integrated in the supplied charger. -
Page 22: Charging
3. E-drive. • The charger may only be used to charge the supplied rechargeable batteries. Any other use of the charger is not permitted. 3.2.1 Charging The battery pack should be charged first before using it for the first time. Use the supplied char- ger (A) with integrated charge controller. - Page 23 3. E-drive. • For longer trips with high motor power, the battery pack can become very hot. A temperature monitor inside prevents charging at an exces- sive temperature. In such a case, the charger may remain connected. Charging starts automatically when the battery pack has cooled down sufficiently.
-
Page 24: Insertion And Removal
3. E-drive. 3.2.2 Insertion and removal To insert the battery pack, insert it from the back of the sliding rail into the mount below the basket until it clicks into place in the lock. Always remove the key before setting off. To remove the battery pack, turn the key (A) clockwise as far as it goes and hold it in this position. -
Page 25: Switch On
3. E-drive. 3.3.1 Switch on Press the MODE (A) button for at least 3 se- conds until the display becomes active. Then release the button again. Pushing and hol- ding the button serves to protect against unintentional switching on. The system is now ready to ride. -
Page 26: Setting The Assistance Level Or Recovery Level
3. E-drive. 3.3.4 Setting the assistance level or recovery level The drive system provides Support Standard Power three different degrees of Start-up beha- assistance for operation. viour Range To select a higher level of as- sistance, press the arrow up (A) button once. -
Page 27: Charge Status Display
3. E-drive. 3.3.5 Charge status display The display on the top right (A) under “battery pack” constantly shows the battery pack charge status. Depending on the charge level, up to six display segments are illuminated. Number of segments in the display Status of the rechargeable battery pack Battery pack fully charged 1 (flashing) - Page 28 3. E-drive. The active function is represented by an oval symbol (A) above the display line. • Dist - Total kilometre counter All driven kilometre distances are totaled. • Trip - Driven trip All kilometres driven since the last deletion are totaled. See Point 3.3.7 to delete this counter reading. •...
-
Page 29: Deleting Counter Readings
3. E-drive. 3.3.7 Deleting counter readings The following counter readings on the display can be deleted by the user: • Driven kilometres (trip) • Driven time (Time) • Average trip speed (AVG) These meter readings can not be deleted individually, but only together all at once. -
Page 30: Switching The Lighting On And Off
3. E-drive. 3.3.9 Switching the lighting on and off This function makes it possible to ope- rate the lighting with the battery pack of the drive system. To switch on the lighting, keep the but- ton (A) pressed. The lighting will be swit- ched on after approx. -
Page 31: Settings
Please ensure that none of the user's extremities are in the respective area when making adjustments of any kind to minimise the risk of injury. 4.1 Presets The momo motion. is supplied completely assembled. Prior to initial use, however, the following pre-settings must be made. 4.1.1 Handlebar adjustment You can find our scope of delivery for hand- lebars under point 2.9. -
Page 32: Saddle Adjustment
4. Settings. 4.1.2 Saddle adjustment You can find our selection of saddle forms under point 2.9. Saddle height The height of the saddle can be adjusted on the frame saddle tube (A) by pulling the saddle post in or out. In order to adjust the height, please loosen the clamp (B) and bring the saddle into the required height. -
Page 33: Brakes
4. Settings. 4.2 Brakes Various brakes are available for the momo motion. depending on the indi- vidual requirements of the user. 4.2.1 Parking brake The parking brake supports the use when climbing on and off the tricycle and secures it against inadvertently rolling away. To ac- tivate the parking brake, press the lever (A) on the handlebar stem (B) downwards. -
Page 34: Backpedal Brake
4. Settings. 4.2.2 Backpedal brake The backpedal brake is actuated by pedaling backwards. The drive op- tions of the freewheel brake hub and the 3 or 7-gear freewheel brake hub feature a backpedal brake. The backpedal brake is only functional when the chain sits correctly! If the chain jumps off, it is not possible to brake using the backpedal brake! The rear wheel may block in case of strong braking procedures. -
Page 35: Tyres And Hoses
4. Settings. If 1 and 2 occur, the reason may be a lack of brake grease. Ask your spe- cialist dealer to grease the mechanism with special wheel brake grease. After each adjustment of the wheel brake, carry out a brake test. Frequent actuation of the wheel brake may cause the area around the brake to heat up. -
Page 36: Accessories
5. Accessories. 5.1 Dynamic back and pelvic guide pelotte pads All back and pelvic guide pelotte pads can only be used in connection with a holding bracket (see Point 5.6). For depth adjustment of the pelotte pad holding bracket, please loosen the screws (A) on the right and left- hand sides of the support under the saddle, and bring the holding bracket into the requi-... -
Page 37: Push Bar
5. Accessories. 5.3 Push bar The push bar is height adjustable and equipped with an integrated anti-rotation lock. In addition, it can be dismantled. In or- der to adjust the height, please loosen the clamp (A) and bring the push handle into the required height. -
Page 38: Holding Bracket With Mount
5. Accessories. 5.6 Holding bracket with mount The holding bracket (A) with mount (B) permits head, torso or pelvic supports to be attached, which provide the tricycles with additional stability. Included in the scope of delivery is the black bracket adapter, which is mounted onto the T-saddle post. -
Page 39: Crank Shortener (Continuously Adjustable)
5. Accessories. 5.8 Crank shortener (continuously adjustable) The adjustable crank shorteners are to be mounted onto the cranks with clamps. Plea- se note here that the crank shortener mar- ked "R" is to be mounted on the right-hand side and the crank shortener marked "L" is to be mounted on the left-hand side. -
Page 40: Exercise Bike Pedals
5. Accessories. 5.11 Exercise bike pedals The exercise bike pedals are characterised by their integrated balancing weight, whereby the tread surface automatically balances its- elf horizontally. This permits the rider to climb on independently. The strap (A) is adjustable in length, and at the same time provides easy side guidance. To adjust the length of the strap (A) pull on the lower end in order to loosen the strap (A) from the plug (B). -
Page 41: Foot Pans With Leg Guidance
5. Accessories. 5.14 Foot pans with leg guidance See Point 5.13 for the function and settings of foot pans. The leg guidan- ce also stabilises the foot joint and reduces internal rotation of the leg. The adjustment of the leg guidance is to be undertaken through loosening of the screws (A) and moving them in the slotted hole. -
Page 42: Chest Strap
5. Accessories. 5.16 Chest strap The chest strap is attached to the width adjustable back pelotte pad, and, if required, ensures secure posi- tioning of the user. The strap is moun- ted with the aid of the plug lock to the back pelotte pad and threaded th- rough the strap guidance on the click buckle. -
Page 43: Groin Harness, T-Shaped
5. Accessories. 5.18 Groin harness, T-shaped The T-shaped groin harness is moun- ted onto the width adjustable pelvic pelotte pad. The strap is mounted onto the pelvic pelotte pad with the aid of the plug lock and threaded th- rough the strap guidance on the click buckle. -
Page 44: Cleaning And Maintaining
Please also pay attention to our general cleaning and hygiene advice. This can be found at www.schuchmann.de/mediathek. Danger due to rotating parts The motor can start to move unexpectedly when the drive system remains switched on when performing cleaning work on the tricycle. -
Page 45: Disinfection
6. Cleaning and maintaining. 6.1.2 Disinfection Various products can be used for surface disinfection of metal and plastic parts. Liquid disinfectants are available as ready-to-use solutions that are spray- ed on and evenly applied with a soft cloth. Alternatively, wipes pre-soaked with disinfectant can be used to wipe the products over the entire surface. -
Page 46: Maintenance
6. Cleaning and maintaining. 6.3 Maintenance For reasons of user safety and to maintain product liability, maintenance needs to be carried out every 1000 km, however at least once a year, by a specialist dealer (see Point 9.5). The maintenance work carried out must be documented in the maintenance plan (see Point 6.3.2). -
Page 47: Maintenance Plan
6. Cleaning and maintaining. Danger due to unforeseen motor activity The motor can start to move unexpectedly when the drive system remains switched on when working on the tricycle. • Remove the battery pack before any intervention with the tricycle. •... -
Page 48: Repairs
6. Cleaning and maintaining. 6.4 Repairs Tricycle repairs that are not performed by your specialist dealer are at the user’s own risk and discretion. Caution When reinstalling the drive, e.g. after a tyre change on the front wheel, the wheel nuts must be tightened again with a tightening torque of 45 Nm ±... -
Page 49: Controls
6.7 Spare parts Only use accessories and spare parts made by Schuchmann, otherwise you will endanger the user and the warranty becomes void. Should you wish to order spare parts, please contact the specialist dealer who supplied you with the tricycle, stating the serial number (see Point 9.5). -
Page 50: Error Messages And Troubleshooting
6. Cleaning and maintaining. Should a serious incident occur during the service life of the product despite being used as intended, this must be reported immediately to the manufactu- rer and the competent authority. 6.9 Error messages and troubleshooting If errors occur during operation of the drive system, “Error” is indicated on the display. - Page 51 6. Cleaning and maintaining. ERROR_I_OFFSET Error Current measurement error, contacts on the battery pack may be damaged Remove the battery pack and check the contacts. If the contacts are OK, reinsert the battery pack and restart the system. Please contact your spe- Measure cialist dealer (see Point 9.5) if the contacts on the battery pack are visibly damaged or the error continues to occur.
- Page 52 6. Cleaning and maintaining. ERROR_PARAMETER Error General parameter error Restart the system. Please contact your specialist dealer (see Point 9.5) if Measure the error continues to occur. ERROR_UNDER_TEMP_MOTOR Error Lower limit temperature for motor operation reached Store the system at room temperature (approx. 20°C). Please contact your Measure specialist dealer (see Point 9.5) if the error continues to occur after approx.
- Page 53 6. Cleaning and maintaining. ERROR_BMS_VERSION Error Loose contact or other defect on the torque sensor Restart the system. Please contact your specialist dealer (see Point 9.5) if Measure the error continues to occur. 22-30 ERROR_BMS_FAULTY_xxx Error Rechargeable battery pack error Measure Please contact your specialist dealer (see Point 9.5).
-
Page 54: Technical Data
7. Technical data. 7.1 Dimensions 16“ 20“ 24“ 26“ 26“ (XL) Recommended body 100 - 115 115 - 130 130 - 145 145 - 160 155 - 180 height Pedal to top edge of 42 - 57.5 50 - 64.5 56.5 - 73.5 66.5 - 83 74 - 90.5... -
Page 55: Drive System
7. Technical data. 7.2 Drive system System Protection class Control Operating voltage 36 V Max. current depending on design & operation: 10 - 33 A Motor Type PRA 180-25 Motor nominal voltage 22.8 VAC Output 250 W Pedelec (DIN EN 60034-1) depending on design &... -
Page 56: Lighting System
7. Technical data. 7.3 Lighting system Front lighting Type AXA Pico 30-E 6V-42V Luminous intensity 30 lx 50 m Be seen 3000 m Lateral visibility Including reflector On/off switch Automatic light/dark sensor Parking light Daytime running light Suitable for E-bike Yes, 6-42 V Primary colour black... -
Page 57: Torque Specifications
7. Technical data. 7.4 Torque specifications Pedal crank 40 Nm Front wheel 20 Nm - 22 Nm Wheel nuts (front wheel) 45 Nm ± 5 Nm Wheel nuts (rear wheels) 25 Nm to 30 Nm Wheel brake cable adjusting nut 1-2 Nm 7.5 Tyre pressure The minimum and maximum tyre pressure is... -
Page 58: Identification
Tel. +49 (0) 5402 / 40 71 00 · Fax +49 (0) 5402 / 40 71 109 erklärt in alleiniger Verantwortung, dass das nachfolgend genannte Produkt der Risikoklasse 1 declares under our sole responsibility that the following product(s) of Class 1 Medical Devices „momo motion.“ Dreirad mit elektrischem Antrieb tricycle with electric drive Art.-Nr. / Item-No.:... - Page 59 EU Konformitätserklärung EU Declaration of Conformity Firma / Company Schuchmann GmbH & Co. KG Rudolf-Runge-Str. 3 · 49143 Bissendorf · Deutschland / Germany Tel. +49 (0) 5402 / 40 71 00 · Fax +49 (0) 5402 / 40 71 109 DIN EN 15194:2018 Fahrräder mit elektrischer Unterstützung...
-
Page 60: Serial Number / Date Of Manufacture
Product labelling in accordance with MDR 9.3 Product version The momo motion. is available in five sizes (16" - 26" XL) and can be supple- mented through a diverse range of accessories (see Point 5). 9.4 Issue of the document momo motion instructions for use.
