Schuchmann madita Instructions For Use Manual
The mobile therapy chair which grows with the child
Hide thumbs
Also See for madita:
- Instructions for use manual (24 pages) ,
- Assembly instructions (5 pages)
Related Manuals for Schuchmann madita
Summary of Contents for Schuchmann madita
- Page 1 Instructions for use. madita. The mobile therapy chair which grows with the child.
- Page 2 Instructions for use may deviate from your product due to differing equipment. We reserve the right to make technical modifications. Important information! Ensure that these Instructions for use remain with the product. Your schuchmann Team...
-
Page 3: Table Of Contents
Contents. 1. Preparation................. 05 1.1 Delivery ..........................05 1.2 Safety measures prior to use ................05 1.3 Safe disposal .......................05 1.3.1 Packaging ......................05 1.3.2 Product ........................05 1.4 Where to store the Instructions for use ............05 2. Product description..............06 2.1 Material information ....................06 2.2 Handling / transport ....................06 2.3 Application areas, use according to the intended purpose ....06 2.3.1 Indications ......................06... - Page 4 Contents. 4.11 Wheel base extension ..................20 5. Cleaning and servicing..............20 5.1 Cleaning and disinfecting ..................20 5.1.1 Cleaning ......................20 5.1.2 Disinfection ......................21 5.2 Servicing ........................21 5.3 Maintenance ....................... 21 5.3.1 Maintenance specifications ..............21 5.3.2 Maintenance plan ..................22 5.4 Spare parts .........................
-
Page 5: Preparation
1.4 Where to store the Instructions for use Please store these Instructions for use carefully and ensure that these Instructions for use remain with the product in case of re-use. Should you lose the instructions, you can always download an updated version at www.schuchmann.de . -
Page 6: Product Description
The user must not be in the therapy chair while it is being transported! 2.3 Application areas, use according to the intended purpose The madita. therapy chair which grows with the child, is a medical product of risk class 1 and designed for use at home, in nurseries and at school. It can be used for all ages from early childhood to teenage years. -
Page 7: Use Not In Accordance With The Intended Purpose / Warning Gui
• Only use accessories and spare parts made by Schuchmann, otherwise you will endanger the user. • Only use the therapy chair if all components have been correctly mounted and adjusted. -
Page 8: List Of Accessories
2. Product description. 2.6 List of accessories • Headrest • Removable back • Thorax pelotte pads (also foldable) • Thigh guide • Adjustable pelvic guide • Therapy table • Knee abduction wedge • Wheel base extension • Strap assembly kit for the seat area •... -
Page 9: Settings
3. Settings. Settings and adjustments to the product or accessories may only be made by people who have been given the necessary instructions by a medical product advisor. Please ensure that none of the user's extremities are in the respective area when making adjustments of any kind to minimise the risk of injury. -
Page 10: Seat Angle
3. Settings. 3.2 Seat angle The lever for the seat angle adjust- ment is equipped with a child lock. In order to adjust the angle of the seat unit, the hand trigger (A) at the rear below the seat pan holder must be actuated by pushing it together hori- zontally until it engages. -
Page 11: Back Height
3. Settings. 3.5 Back height Loosen the cylinder head screw (A) with an Allen key (M8) at the rear and bring the back into the desired height. 3.6 Armrests The armrests can be adjusted in angle, height and width. The angle is adjus- ted after loosening the star knob (B). -
Page 12: Foot Support
3. Settings. 3.7 Foot support The basic model of the madita. thera- py already includes a foot support (A). It has a non-slip surface (B) and has 8 slits (C) to attach straps such as foot cuffs or foot positioning aids. -
Page 13: Footrests
3. Settings. 3.8 Footrests Optionally madita. can also be equip- ped with footrests (A). They have an anti-slip surface (B) and have 4 slits each (C) to mount straps such as foot cuffs or foot positioning aids. To adjust the knee angle, please relea-... -
Page 14: Positioning Of The Footrests
3. Settings. 3.8.1 Positioning of the footrests For optimum positioning of the feet, the footrests can be adjusted inde- pendently of each other in width, angle and depth. Foot angle The foot angle (A) of the respective footrest can be adjusted from (-)15° to 5°. -
Page 15: Footrests With Foot Pans
3. Settings. 3.9 Footrests with foot pans Optionally, the footrests can also be equipped with foot pans (A). Here, as on the standard design, the knee angle can be adjusted, the foot pans folded up and the height adjusted (see Point 3.8). For optimum positio- ning of the feet, the footrests with foot pans can be adjusted independent- ly of each other in width, angle and... -
Page 16: Accessories
4. Accessories. 4.1 Headrest The headrest can be adjusted in height, depth and angle. In order to do this, please loosen the 2 cylinder head screws (A) with a hexagonal wrench and bring the headrest into the requi- red position. 4.2 Removable back The removable back can be operated at the rear of the therapy chair. -
Page 17: Thorax Pelotte Pads
4. Accessories. 17 17 4.3 Thorax pelotte pads The thorax pelotte pads are individu- ally adjustable in height and width. In order to do this, please loosen the 2 pan head screws with a hexagonal wrench (A) and bring the thorax pelot- te pads into the required position. -
Page 18: Thigh Guide
4. Accessories. 4.6 Thigh guide The thigh guide pads are individual- ly adjustable in height and depth. In order to adjust the width, loosen the two wing screws (A) under the seat area and bring the thigh guide pad into the required position. The depth adjustment is possible on any thigh guide except on the standard version for Size 0 with adjustable pelvic guide. -
Page 19: Adjustable Pelvic Guide
4. Accessories. 4.8 Adjustable pelvic guide The adjustable pelvic guide can be adjusted in width, provides the user with a high level of security and po- sitions the pelvis. At first, loosen the cylinder head screw (A) on the rear of the therapy chair at the bottom edge of the cover. -
Page 20: Knee Abduction Wedge
For all removable fabrics please pay at- tention to the sewn-in care labels (such as A + B) on the Obermaterial/ top cloth/dessus: respective element. 100% Polyester Please also pay attention to our general clea- ning and hygiene advice. This can be found at www.schuchmann.de/mediathek. -
Page 21: Disinfection
5. Cleaning and servicing. 5.1.2 Disinfection Various products can be used for surface disinfection of metal and pla- stic parts. Liquid disinfectants are available as ready-to-use solutions that are sprayed on and evenly applied with a soft cloth. Alternatively, wipes pre-soaked with disinfectant can be used to wipe the products over the entire surface. -
Page 22: Maintenance Plan
5. Cleaning and servicing. • Legibility of the type label • Final complete functional check of the aid • Check that all mounting parts and associated accessories are correctly fastened 5.3.2 Maintenance plan Maintenance specifications of the manufacturer (see Point 5.3.1) were car- ried out: Date Company... -
Page 23: Spare Parts
5. Cleaning and maintaining. 5.4 Spare parts Use only original accessories and original spare parts from Schuchmann, as otherwise the safety of the user is endangered and the warranty expires. To order spare parts, please contact the supplying specialist dealer (see point 8.5) stating the serial number of the product. -
Page 24: Technical Data
6 . Technical data. Dimensions Size 0 Size 1 Size 1b Size 2 Seat depth 15-25 cm 21-30 cm 26-36 cm 30-42 cm Seat width 16-26 cm 20-30 cm 20-30 cm 28-38 cm Back height with 35-43 cm 35-43 cm 42-52 cm 42-52 cm short back... -
Page 25: Guarantee
7. Guarantee. The two-year statutory guarantee period shall apply for all products. This begins with the delivery or handover of the goods. Should a verifiable material or manufacturing fault occur within this time period, we shall, after carriage paid return to us, view the indicated damage and, if applicable, either repair or deliver a new product at our discretion. -
Page 26: Identification
EU Konformitätserklärung EU Declaration of Conformity Firma / Company Schuchmann GmbH & Co. KG Rudolf-Runge-Str. 3 · 49143 Bissendorf · Deutschland / Germany Tel. +49 (0) 5402 / 40 71 00 · Fax +49 (0) 5402 / 40 71 109 erklärt in alleiniger Verantwortung, dass das nachfolgend genannte Produkt der Risikoklasse 1... -
Page 27: Serial Number / Date Of Manufacture
• info@schuchmann.de • Fon +49 (0) 5402 / 40 71 00 Product labelling in accordance with MDR 8.3 Product version The madita. therapy chair is available in four sizes and can be supplemented by a varied range of accessories (see Point 4). 8.4 Issue of the document Instructions for use madita. - Page 28 schuchmann.de...
