- Page 1 SUNVERTER 3 AC SOLAR PUMP CONTROLLER Installation & Operating Manual...
- Page 3 INDEX CONTROLLER SPECIFICATIONS 2. SYMBOLS & WARNINGS 2.1 Purchase Inspection 2.2 Installation 2.3 Wiring 2.4 Connection 2.5 Running 2.6 Hybrid Operation 2.7 Others 3. INSTALLATION & WIRING 3.1 Installation Direction 3.2 Installation Method 3.3 Wiring Diagram 3.4 Electrical Connection 3.5 Single Phase Motor Wiring Installation 3.6 Water Level Switch Installation &...
- Page 4 5. TROUBLE SHOOTING 5.1 Fault Code Description & Solutions 5.2 Fault Page Display Description 5.3 Faulty & Abnormal Code Description 5.4 Faulty Inquiry & Reset 5.5 Important Note Description 5.6 Important Note Page Display Description 5.7 Important Note Code Description SERVICE &...
- Page 5 Pump Solar Water Pumping System Layout Dayliff Sunverter 3 is the latest update of the established Sunverter range of advanced AC/DC inverters specially designed for solar-powering AC motors in various water pumping applications. As well as a general upgrade of the electronics and functionality an important new feature is hybrid capability that enables concurrent operation with direct AC power from mains or generator supply while prioritising solar supply.
- Page 6 INSTALLATION Dayliff Sunverter 3 controllers are surface mounted and should be provided with a housing for water and heat protection. They must also be provided with a circuit breaker between the PV modules and controller. Due to the high operating voltages proper earthing is essential, which must be done by a qualified electrician.
- Page 7 All dimensions in mm 2. SYMBOLS AND WARNINGS Misuse will result in re, serious injury to persons or even death. WARNING Misuse will cause low or middle-level injury to person or equipment damage. CAUTION 2.1 Purchase Inspection Check the inverter before installation. Do not install if it is damaged or with missing parts, else may cause accidents.
- Page 8 2.3 Wiring Wiring must be performed by a qualied electric professional, else may cause electric shock or re. WARNING Always ensure input power is isolated before wiring and connection; else may cause electric shock or re. WARNING Earth terminal must be reliably grounded, or else inverter enclosure may be electried.
- Page 9 For areas with altitude over 2000m, the inverter output current should be derated at 10% for every 1500m increase in altitude. CAUTION 2.6 Hybrid Operation Do not switch off DC or AC power to the inverter while the pump is running. The disconnect switch and/or MCB should only be operated after the inverter is in stop mode otherwise CAUTION there will be damage .
- Page 10 A >100mm B>200mm B>300mm for 11kW Fig 1: Installation Direction Diagram The installation surface should be at and closely attached to the inverter bottom surface to ensure good heat dissipation. NOTE If multiple inverters are to be installed in the same cabinet, it is recommended to adopt side by side installation.
- Page 11 Dimensions (mm) Model SV3/1.5M SV3/2.2M SV3/3.7M SV3/3.7T SV3/5.5T SV3/7.5T SV3/11T SV3/15T SV3/18T SV3/22T Do NOT install the inverter on rocks or thin wooden panels with toggle bolts. NOTE The expansion bolts provided by manufacturer are suitable for installation on concrete walls. If the inverter is to be mounted on wooden walls, select the expansion bolt suitable NOTE for wooden wall mounting, and ensure the expansion bolts...
- Page 12 Fig 5: Wiring Terminal Diagram Connection Description Terminal Description Socket C o n n e c t e d t o p o s i t i v e electrode of solar pv array DC Input C o n n e c t e d t o n e g a t i v e electrode of solar pv array Connected to R phase of grid Connected to S phase of grid...
- Page 13 The input/output sockets are different for models, subject to the silk screen on the inverter sockets and the terminal description. CAUTION For single-phase pumps, remove the external capacitor before wiring NOTE Terminal Terminal Name Function Description Tank water level signal input, open circuit is normal, short circuit is abnormal.
- Page 14 In order to ensure communication quality, use twisted shielded pair cable as communication cable. NOTE All cables, analog, digital, power and signal should be separated to avoid entanglement. NOTE Solar Array AC Cable (mm ) Earth Cable (mm ) Signal Cable Model Cable (mm ) (mm )
- Page 15 3.4 Electrical Connection Step 1 : Prepare all the input/output cables as shown in Fig 6. Single Core Cable Multi Core Cable Stripping Diagram Stripping Diagram Fig 6: Wire Process Diagram Solar Array Process Description Type Cable Strip 10mm at A Single-Core DC Cable Strip 50mm at A, Strip 10mm at B...
- Page 16 Step 3: Upon completion tighten the bottom waterproof PG terminal, close the wiring area cover and lock it with a tightening torque between 10Nm and 12Nm. Step 4: Fix the earth cable to the ground screw at the bottom of the shell as shown in Fig 8.
- Page 17 Fig 10: Single phase Inverter Wiring Diagram Ensure to connect the wires according to the instructions, incorrect connection may lead to abnormal operation of the system. CAUTION Wiring Reminder In case single phase pump motor connection parts cannot be recognized, perform the following steps to identify Step 1: Test the resistance between each pair of the connection parts with a multi- meter, the two ports with largest resistance value should be the main winding...
- Page 18 To wire for well application, pass the water level switch cable through the waterproof PG terminal and connect to the I3 and COM terminals(remove the short-circuit strip between the two first), for tank application, connect to the I1 and COM terminals as shown in Fig. 12. Fig 11: Water Level Switch Fig 12: Water Level Switch Installation for Well/Tank...
- Page 19 3.8 Hybrid Installation SV3 series solar pumping inverter provides PV and AC hybrid power input function, as shown below, PV input is connected to bus circuit through anti-reverse diode. Through anti-reverse diode and AC power input is rectified through rectifier bridge then connected to bus circuit.
- Page 20 Vrms is the effective voltage value of AC power, such as 1PH 220V/3PH 380V NOTE Power Pmax Imax Vmax V Voltage PV Array Curve Max DC Motor Output Rated Solar Rated Input Input Current Voltage Model Output Power Voltage Power Voltage (kW) (kWp)
- Page 21 4. OPERATION AND CONTROL 4.1 Initial Settings before First Operation While implementing initial settings below, refer to section 4.6 on how to view and modify parameters as well as section 4.7 for detailed parameter descriptions Step Initial Setting Content Operating Method Modify all control parameters as read- Modify Pr.0 value to 0.
- Page 22 Step Initial Setting Content Operating Method Modify Pr. 7 value to 1, enable the inverter to run in MPPT Restore frequency adjustment mode mode. Modify the control parameters as read Modify Pr. 0 parameter value to 1 before the inverter only restart.
- Page 23 Indicator Lights & Name Function Keys Green On: Inverter is running Running Indicator Light STOP Shutdown Indicator Light On: Inverter is shut down Fault Indicator Light On: System fault FAULT Green On: System normal NORMAL Normal Indicator Light On: Water tank or well water level is ABNORM Abnormal Indicator Light abnormal...
- Page 24 4.3 Panel Operation There are 3 kinds of status for operating panel display: running data display, control parameter display and historical data display. The default status is the running data display. Press the key to enter the status of control parameter PROG display, and press the key again to return the default status.
- Page 25 Description Operation Display Display current running data: Display current running data: Water flow, pipeline pressure, Water flow, pipeline pressure, liquid, level depth and total liquid, level depth and total MODE energy generation. energy generation. 4.5 View Historical Data Description Display Operation Initial Status: Non historical running data...
- Page 26 4.6 View or Modify Control Parameter Description Display Operation Initial Status: non-control E n t e r t h e p a r a m e t e r parameter display modification interface: Display menu type, parameter number, PROG parameter value, parameter meaning of the inverter.
- Page 27 4.7 Function Parameter Description Factory Scope Description Name Number Value 0: Parameter can be read and edited. Other parameter values cannot be modified until this parameter is modified to 0. Parameter Set 1: All parameters can only be read. Pr.0 Mode 2.
- Page 28 Factory Scope Description Number Name Value Reference Target frequency when Pr.7 is O. Unit: Hz Pr.12 0-Pr.13 30.00Hz Frequency To protect the motor load, maximum operating Maximum frequency must be same as rated frequency of Operating Pr.13 0.01-60.00 50.00Hz motor. frequency Associated with the output V/F curve Once the output frequency is less than the set...
- Page 29 Factory Scope Description Number Name Value Fault Type Record the last 4 fault codes. It will only display the Read Only Pr.20-23 first six characters of the fault code here for Record d e s c r i p t i o n s s e e c h a p t e r 4 . Start delay time in seconds after power on or Start delay time 1-6000...
- Page 30 5. TROUBLE SHOOTING 5.1 Fault Code Description and Solution Sv3 solar pumping inverter is provided with full protection. When a system fault occurs, the inverter stops the pump for a certain period of time before restarting. When protection occurs, the inverter screen will automatically switch to the fault display page.
- Page 31 Warning Counter Measures Possible Reason Code Description Code Over Inspect solar array voltage Over Voltage High input voltage Voltage Inspect solar array voltage. Incase it is Low input voltage Under Voltage sunny and yet warning code persists, Weak sunlight intensity Voltage increase Pr.1 slightly to not more than 0.9.
- Page 32 Warning Counter Measures Possible Reason Code Description Code Inspect AC power supply cable Phase loss 3 phase AC power supply Lose phs connections protection phase lost Abnormal Counter Measures Possible Reason Code Description Code Wait for the water level to return to normal, system will begin countdown to Water level abnormal restart...
- Page 33 5.5 Important Note Description If there are operations such as important parameter modification or user parameter initialization, SV3 will automatically jump to the important note page. 5.6 Important Note Page Display Description LCD Display Column Description Flashing display of important note code Alert Displays inverter model Model...
- Page 34 PROBLEM POSSIBLE CAUSE SOLUTION Indicator light is off Check DC input wires connection Inverter does not work when powered Cut of inverter input wires and check if Indicator light is on input voltage is abnormal Reset the motor starter overload. If it trips again, check the voltage else call service The motor overload has tripped out technician...
- Page 35 PROBLEM POSSIBLE CAUSE SOLUTION The water level sensor not installed Check water level sensor and correct correctly Frequent starts Pull out the pump and clean or replace The non-return valve is leaking or stuck the non-return valve and stops half open Increase the installation depth of the pump, throttle the pump or replace it The pump is oversized for borehole...
- Page 36 6. SERVICE AND MAINTENANCE 6.1 Routine Inspection and Maintenance Sunverter is affected by ambient temperature, humidity, dust, vibration and internal device aging. To ensure long term operation a yearly inspection is recommended. 6.2 Requirement of Inspection and Maintenance The inspection must be performed by a qualified technician. Ensure to cut off power supply of the inverter before carrying out any repair.
- Page 37 6.4 Inspection and Replacement of the Damageable Part Filter Capacitor The pulsating current of the main circuit will influence the performance of the aluminum electrolytic filter capacitor depend on the ambient temperature and the application condition. The electrolytic capacitor of the sunverter should be replaced after 10 years, however, if the filter capacitor’s electrolyte is leaking or the safety valve bursting out of the capacitor main body is expanding it should be replaced immediately.
- Page 38 General Liability • In lieu of any warranty, condition or liability implied by law, the liability of Dayliff (hereafter called the Distributor) in respect of any defect or failure of equipment supplied is limited to making good by replacement or repair (at the Distributor’s discretion) defects which under proper use...
- Page 40 www.davisandshirtliff.com INS475A-03/21...
