1.75" Coil Spacer Lift Kit Installation: Front
FIG1
Caution: Park the vehicle on flat, level
ground and set emergency brake. Put
on safety glasses. Raise the front of the
vehicle and support frame rails using
jack stands. Do not lower the axle at
FIG3
Remove the upper control arm bushing
heat shields on the frame using a 10mm
socket and or wrench. (FIGs 3 & 4)
QJL_1.75_LIFT_16400_0010_LTR.indd 4 QJL_1.75_LIFT_16400_0010_LTR.indd 4
FIG2
this time. Remove front wheels/tires.
Loosen the front track bar at both the
frame and axle using a 21mm socket
and wrench. (FIGs 1 & 2) Remove bolt
from the axle end and save hardware.
PARK THE VEHICLE ON FLAT, LEVEL GROUND AND SET EMERGENCY BRAK
E. ALWAYS SUPPORT FRAME RAILS USING JACK STANDS.
FIG4
