11.2
Terminal diagram for the CUP electronic card
Legend:
1 Valve
2 pump
3 Motor
4 Limit switch
11.3
Pin assignment
Legend:
UB 24V voltage monitoring (OUT)
SC Sample/Clean Signal (IN)
PE Earth, green/yellow (Protection Earth)
(1) Electrical Requirements
(2) dimensions
7821-9001-005
01. October 2019
7801-9047-030
Appendix
Pin assignment
1
2
3
4
93 / 100
