4.2 Transport
The cable and hose must be stowed in the space provided in the bottle rack to
ensure they are not damaged during storage or transport.
Transport requirements:
● The two drain channels must go into the
positions provided.
● The sampling hose and connecting
cable must be placed behind the
positioning device in the box.
● The plug on the connecting cable must
be fed through the positioning device to
the back.
● Alternatively, the plug may be fastened
to the positioning device with a cable tie.
● A bottle rack can also be transported in
the sampler.
22 / 100
- The rear drain channel in the
positioning device
- The front drain channel in the wall of
the box
Attention!
Trapped lines
The lines must not get trapped when the sampler is closed.
Note
Not recommended! The total weight will then be more than 25 kg.
