Spare Parts; Milk Sampling Device - GEA DairyRobot R9500 Operation Manual

10

Spare Parts

10.1

Milk sampling device

Item
0020
0030
0040
0050
0060
0070
0080
0090
0100
0120
0130
0150
0160
0170
0180
0190
0200
0210
0220
0230
7821-9001-005
01. October 2019
Part no.
Milk sampling device
7801-2503-000
(without bottle rack)
7801-2187-070 Bracket, complete
7821-2503-000 Sampler complete
0019-5575-300 Saucer-head screw
0026-1345-300 washer
0019-9101-300 Cheesehead screw
Milk sampling device
7800-0025-657 Cover holder
7800-0025-663 Distance bush
0019-6901-300 Hexagon head bolt
0026-0439-300 washer
7800-0025-678 Lock washer
7801-1268-020 Drain channel, welded
7801-1268-000 Drain channel, welded
0019-9100-300 Cheesehead screw
0026-0429-300 washer
0026-1362-300 washer
0013-0310-300 Hexagon Head Nut
0019-6845-300 Hexagon head bolt
0026-0922-300 washer
0013-0294-300 Hexagon Head Nut
See corresponding parts list/drawing for further breakdown of components.
Milk sampling device
Description
MIone Metatron
M8x25
8,4
M4x20
MIone Interrior
M8x56
M8x16
8,4x24x2
7
Duo Compact II
rear
M4x16
5,3x15x1,2
4,3
M4
M6x25
6,4x18x1,6
M6
Spare Parts
81 / 100
