GEA DairyRobot R9500 Operation Manual page 85

Set of spare parts
110
120
130
140
Item
0010
0020
0030
0040
0050
0060
0070
0080
0090
0100
0110
0120
0130
0140
0150
7821-9001-005
01. October 2019
Part no.
7821-9905-030 Set of spare parts
7021-7106-060 Milk sampler hose, silicone
0007-3239-890 Sealing ring
0007-2509-700 Sealing ring
0007-1974-700 Sealing ring
7161-1467-000 Sealing panel
0007-2060-700 Sealing ring
0007-1818-700 Sealing ring
7021-7106-058 Milk sampler hose, silicone
7021-7106-058 Milk sampler hose, silicone
7021-7106-058 Milk sampler hose, silicone
0018-4376-898 tube
0018-0380-848 Pipe
0026-2249-890 Cap
0018-5324-820 Y-hose connector
7021-7106-050 Milk sampler hose, silicone
Milk sampling device
Description
8,5x3,75x320 Sil gn
D1in Tri-Clamp Sil
8 X 2
10x2
36x20xD4
66 x 6
9 x 2
8,5x3,75(x25.000) Sil
gn (210 mm)
8,5x3,75(x25.000) Sil
gn (110 mm)
8,5x3,75(x25.000) Sil
gn (120 mm)
ID4xOD7(xL25.000)
Sil tp (160 mm)
OD8xID6 Pla na (170
mm)
ID4 Pla rd
OD10x90Deg Pla
8,5x3,75x225 Sil gn
Spare Parts
20
30
40
70
60
50
10, 80, 90,
100, 150
85 / 100
