Maintenance
Inspections and preventive maintenance
8.3.4 Checking and adjusting the limit switch trigger point
The trigger point may change over time and therefore has to be checked regularly.
● Connect the cable to the automatic milking system.
● Press the "RESET" button.
● Open the catch on the top of the cover.
● Briefly press the button on the right of
the electronic card.
● Check the nozzle's first filling position.
● Press the "RESET" button.
78 / 100
- The filling nozzle will be heard moving to the start position.
- The filling nozzle
position further.
- The filling positions are marked by
notches.
- The filling nozzle moves back to the start position.
moves one
