Sampling device

Description of the operating elements

5.3 Description of the operating elements
Operation is via the controls on the sampling device and via the system computer
belonging to the automatic milking system.
Milk sampling device
Legend:
L Indicator lights
T1 RESET button
T2 PUMP button
S Selector switch
System computer
System computer control panel/user interface
Operated by touching the screen.
26 / 100
See instructions for further information on the subject
7821-90 . . -000
On indicator (green)
Move filling nozzle to the start
position
Operate the hose pump manually
Set sample quantity
L
T1
T2
S
7821-9001-005
