GEA DairyRobot R9500 Operation Manual page 76

Maintenance
Inspections and preventive maintenance
8.3.3 Replacing the chain and sprockets
The chain comes correctly pre-tensioned from the factory.
It is not necessary to re-tension the chain because of the very slight wear.
As a rule the chain will not have to be changed for several years.
● Undo the four screws holding the
sampling equipment in the lid.
● Turn the sampling equipment out of the
lid so that the chain is on top.
● Loosen the threaded pin on the
sprocket (drive) with a spanner.
● Place a spanner on the square of the
chain tensioner and loosen the chain.
76 / 100
Warning!
Danger from automatic start
The conveyor chain can start to move when work is being carried out.
There is a risk of crushing and electric shock.
► Disconnect the cable from the power supply before starting the work.
7821-9001-005
01. October 2019
