Models / Size Chart; Marking; Nomenclature - Climbing Technology YPSILON Manual

1

MODELS / SIZE CHART

MODEL YPSILON
REF. No. 7W12930060
L1
L1=30 cm
L2=60 cm
L2
L3=80 cm
L3
MATERIAL
16 mm
WEIGHT 90 g
22 kN
STANDARDS
EN 354:2010 / EN 566:2017
4
EN 354 / EN 566 - BREAKING LOADS
22 kN
22 kN
22 kN 22 kN
4.1 4.2
NO!
DANGER
15 kN
4.5
Climbing Technology by Aludesign S.p.A. via Torchio 22
24034 Cisano B.sco BG ITALY
2
4
YPSILON
PA
1
22 kN
22 kN
22 kN
4.3 4.4
NO!
DANGER
4.6
www.climbingtechnology.com

MARKING

6 2 7 11
EN 566:2017
0333
EN 354:2010
Art.7W12930060
22 kN
Made in Europe
Aludesign S.p.A. Via Torchio,22 - 24034 Cisano B.Sco ITALY
8 T9 T8 T2 13 14
OK!
15 kN
4.5
NO!
DANGER
4.7
3

NOMENCLATURE

12
30
B
D
I
E
NO!
DANGER
4.6
IST52-7W129CT_rev.2 05-21
