3.3 MIM-1GEF/MIM-2GEF Module
3.3.1 Introduction
MIM-1GEF/MIM-2GEF is short for 1/2-port 1000Base-SX/1000Base-LX GE fiber
interface module, where GE is short for Gigabit Ethernet and F for fiber, indicating
optical fiber interface. MIM-1GEF/MIM-2GEF is used for the communication between
router and LAN.
MIM-1GEF/MIM-2GEF supports:
Five types of 1000Base-LX/1000Base-SX SFP removable modules: multi-mode
short-haul (850 nm), single mode medium-haul (1310 nm), single mode long-haul
(1310 nm), single mode long-haul (1550 nm), and single mode ultra-long haul
(1550 nm)
1000 Mbps interface rate
Full duplex
3.3.2 Interface Attributes
The interface attributes of MIM-1GEF/MIM-2GEF are given in the following table:
Table 3-5 Interface attributes of MIM-1GEF/MIM-2GEF
Attribute
Number
interfaces
Connector
Interface
standard
Trans
mitting
optical
power
Receiver
sensitivity
Central
wavelength
MIM-1GEF
of
1
SFP/LC
802.3, 802.3u, 802.3ab
Multi-mode
Type short-haul
(850 nm)
Min. –9.5 dBm
Max. 0 dBm
–17 dBm
850 nm
Chapter 3 Multifunctional Interface Modules
Description
2
Single
mode
medium Long-haul
-haul (1310 nm)
(1310
nm)
–9 dBm –2 dBm
–3 dBm 5 dBm
–20
–23 dBm
dBm
1310 nm 1310 nm
3-6
MIM-2GEF
Long-haul Ultra-long
(1550 nm) (1550 nm)
–4 dBm –4 dBm
1 dBm 2 dBm
–21 dBm –22 dBm
1550 nm 1550 nm
