2.4 SIC-1TPRI/SIC-1T1-F

2.4.1 Introduction

1-port channelized T1/CT1/PRI compatible interface card (SIC-1TPRI) supports:
Transmission/Receiving and handling of T1 data streams;
CT1 (channel T1) access;
ISDN PRI function;
Remote loopback and local loopback, facilitating the effective and flexible
debugging.
It is possible to use the card for multiple purposes through different configurations.
Following are the differences between SIC-1TPRI and 1-port Fractional T1 interface
card (SIC-1T1-F):
FT1 mode of SIC-1T1-F can support only one channel bundle (the rate is n × 56
kbps, n=1-24), while the 24 channels can be grouped into multiple arbitrary
bundles by SIC-1TPRI.
SIC-1T1-F does not support PRI mode.

2.4.2 Interface Attributes

The interface attributes of SIC-1TPRI/SIC-1T1-F are given in the following table:
Table 2-8 Interface attributes of SIC-1TPRI/SIC-1T1-F
Connector type
Number of connectors
Interface standard
Interface rate
Cable type
Operating mode
Attribute
RJ-45
1
G.703/T1.102
G.704
AT&T TR 54016
AT&T TR 62411
ANSI T1.403
1.544 Mbps
T1 cable (100-ohm standard shielded network cable)
CT1, ISDN PRI (supported by SIC-1TPRI only)
FT1(supported by SIC-1T1-F only)
