OWNER/OPERATOR'S MANUAL
& ILLUSTRATED PARTS LIST
MODEL:
73-70805 TREE FARM MOWER 44 MC400
WARNING: If incorrectly used this machine can cause severe injury. Those who use
and maintain this machine should be trained in its proper use, warned of its dangers
and should read the entire manual before attempting to set up, operate, adjust or
service the machine.
09-323 REV A
Advertisement
Table of Contents
Related Manuals for Textron JACOBSEN MC400
Summary of Contents for Textron JACOBSEN MC400
- Page 1 OWNER/OPERATOR’S MANUAL & ILLUSTRATED PARTS LIST MODEL: 73-70805 TREE FARM MOWER 44 MC400 WARNING: If incorrectly used this machine can cause severe injury. Those who use and maintain this machine should be trained in its proper use, warned of its dangers and should read the entire manual before attempting to set up, operate, adjust or service the machine.
- Page 2 © 2003, TEXTRON INC...
-
Page 3: Table Of Contents
Jacobsen designs and builds its equipment to serve many years in a safe and productive manner. For longest life, use this product only as directed in the manual, keep it in good repair and follow safety warnings and instructions. You'll always be glad you did. Jacobsen, a Textron Company One Bob Cat Lane Johnson Creek, WI 53038-0469... -
Page 4: Introduction / Specifications
INTRODUCTION / SPECIFICATIONS TREE FARM MOWER DESCRIPTION The Model MC400 Tree Farm Mower is designed to fit the 420 tractor equipped with standard tires or optional 20 X 8.00-10 turf type tires. The mower is easy to attach and detach in a minute or less allowing interchange with many other front mounted attachments. -
Page 5: Safety
Your safety and the safety of others is involved. Jacobsen, a Textron Company strongly warns Signal word definitions against, rejects and disclaims any modifications, add-on accessories or product alterations that are... - Page 6 SAFETY TREE FARM MOWER GENERAL SAFETY 1. Read and understand the Owner’s Manual before attempting to operate this machine. 2. Operate all controls from the operator’s seat. NO RIDERS. 3. Keep all shields in place and safety switches adjusted properly. 4.
-
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS TREE FARM MOWER 1. Remove mower from crate. 2. Remove top shield and remove bag of small fastener parts. Separate according to size. 3. If optional 20 X 8.00-10 turf-type tires are being used, move each wheel hub in toward the center of the tractor a distance of 3/4 inch or a total distance of 1-1/2 inches from the end of the axle. -
Page 8: Installation
INSTALLATION TREE FARM MOWER ATTACHING MOWER TO TRACTOR: 1. Operate latch control to open hitch latches. 2. Drive tractor into position aligning the quick hitch. 3. Be sure both latches engage fully and are laced in the locked position. NOTE: Stop engine! Do not attempt to install drive belt with engine running. 4. -
Page 9: Operation
OPERATION TREE FARM MOWER Observe all Safety Decals. Keep all Shields in place. Do not operate mower with other persons in the area. Irregularities in ground surface can permit foreign material to be propelled from beneath deck to cause serious injury or death. Before leaving tractor, move Forward - Reverse control to neutral position, disengage PTO, set parking brake, lower mower deck and stop engine. -
Page 10: Service
SERVICE TREE FARM MOWER MAINTENANCE Daily maintenance: Visual inspection for loose parts and accumulation of grass and dirt. Clean accumulation of grass clippings from beneath deck daily for better mowing performance. Keep blades sharp. Check the tips of the blades for wear. 25 hour maintenance: In addition to daily maintenance, grease caster, slip yoke and all bearings. - Page 11 SERVICE TREE FARM MOWER Changing Main Drive Belts • 1. Remove the top shield. • 2. Release the idler springs and remove upper drive belt. • 3. Remove the 4 bolts from the right spindle support. Tilt the support and remove the lower drive belt. NOTE: This support will move far enough to allow the lower belt to be removed and installed without loosening any spindle bearings.
- Page 12 SERVICE TREE FARM MOWER SERVICE NOTES:...
-
Page 13: Parts Section
PARTS SECTION TREE FARM MOWER PARTS SECTION... - Page 14 MAIN DECK TREE FARM MOWER FIGURE 1...
- Page 15 MAIN DECK TREE FARM MOWER FIGURE 1 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 47-077 KNOB-SMALL WITH STUD 1-39 64123-70 BOLT-HEX 3/8-16X1-1/2 64002-04 LOCKWASHER, EXT. 5/16 1-40 41-052 SPRING EXTENSION 60-611 SHIELD-TOP 1-41 87-239 GEARBOX 00-093 DECAL-OWNER'S MANUAL 1 1-42 64-802.7 CHAIN RETAINER...
- Page 16 FRAME AND HITCH PARTS TREE FARM MOWER FIGURE 2...
-
Page 17: Frame And Hitch Parts
FRAME AND HITCH PARTS TREE FARM MOWER FIGURE 2 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 53-060 DUST CAP 2-28 80-247 SHAFT-DRIVE 3/4 SQ 99-AC12NFLOCKNUT-3/4 NF 2-29 87-163 U-JOINT-SLIP YOKE 64163-06 WSHR-.768/.756X1.25X14G 2 2-30 87-239 GEARBOX 55-Z9504AB BALL BEARING 2-31 29-109 PIPE NIPPLE-1/4 NPTX2-1/2 2... - Page 18 FRONT WHEEL SHIELDS TREE FARM MOWER FIGURE 3...
-
Page 19: Front Wheel Shields
FRONT WHEEL SHIELDS TREE FARM MOWER FIGURE 3 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 60-522.7 SHIELD-R FRONT WHEEL 53-073 WHEEL ASSY (OPTIONAL) 53-090 TIRE ONLY-20 X 8.00-10 53-085 RIM ONLY FOR 53-073 WHL 1 60-521.7 SHIELD-LEFT FRONT WHL 64141-6 NUT, 5/16-18 64139-08... - Page 20 REAR WHEEL SHIELDS TREE FARM MOWER FIGURE 4...
-
Page 21: Rear Wheel Shields
REAR WHEEL SHIELDS TREE FARM MOWER FIGURE 4 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 64139-04 BOLT-WLF 1/4-20X3/4 64141-2 NUT-WLF 1/4-20 60-529.7 SHIELD-LEFT REAR WHEEL 1 64-643.7 SHIELD BRACKET-LFT R 53-073 WHEEL ASSEMBLY (OPTIONAL) 53-090 TIRE ONLY-20 X 8.00-10 53-085 RIM ONLY 64-644.7... - Page 22 GEARBOX (A) TREE FARM MOWER FIGURE 5...
-
Page 23: Gearbox (A)
GEARBOX (A) TREE FARM MOWER FIGURE 5 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION FOR SERIAL NUMBER 1001 - 1055 87-CM002824 HOUSING HALF (ORDER WITH 87-CM001453) 87-CM001453 HOUSING HALF (ORDER WITH 87-CM002824 87-CM153411 BALL BEARING 87-CM301432 SEAL 87-CM210484 SHAFT 87-CM102111 GEAR 87-CM151282 BALL BEARING 87-CM210559 SHAFT... - Page 24 GEARBOX (B) TREE FARM MOWER FIGURE 6...
-
Page 25: Gearbox (B)
GEARBOX (B) TREE FARM MOWER FIGURE 6 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION FOR SERIAL NUMBER 1056 - 1102 87-CM002824 HOUSING HALF (ORDER WITH 87-CM001453) 87-CM001453 HOUSING HALF (ORDER WITH 87-CM002824 87-CM153411 BALL BEARING 87-CM301432 SEAL 87-CM210484 SHAFT 87-CM151282 BALL BEARING 87-CM107201 SHAFT &... - Page 26 GEARBOX (C) TREE FARM MOWER FIGURE 7...
-
Page 27: Gearbox (C)
GEARBOX (C) TREE FARM MOWER FIGURE 7 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION FOR SERIAL NUMBER 1103 - 1120 87-209 GEARBOX 87-CM003582 HOUSING HALF 87-CM143437 BALL BEARING 87-CM301374 SEAL 87-CM226423 THRU SHAFT 87-CM108068 SHAFT & PINION (LFT) 87-CM143429 BALL BEARING 87-CM620013 RETAINING RING 87-CM640110 EXPANSION PLUG 87-CM108514 GEAR-(RIGHT HAND) - Page 28 GEARBOX (D) TREE FARM MOWER FIGURE 8...
-
Page 29: Gearbox (D)
GEARBOX (D) TREE FARM MOWER FIGURE 8 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION FOR SERIAL NUMBER 1120 - 87-239 GEARBOX 87-CM003913 HOUSING 87-CM056077 BLANK CAP 87-CM414516 WHIZLOCK CAPSCREWS 18 87-CM150094 BEARING CONE 87-CM150102 BEARING CUP 87-CM110064 GEAR (RH) 87-CM056655 HUB 87-CM056648 CAP 87-CM300004 SEAL... - Page 30 Equipment from Jacobsen, a Textron company, is built to exacting standards ensured by ISO 9001 and ISO 14001 registration at all our manufacturing locations. A worldwide dealer network and factory-trained technicians backed by Textron Parts Xpress provide reliable, high-quality product support.
