4.4 Probe Settings

The SONO-VIEW offers the option to comprehensively configure the connected probes even without
PC. Settings such as offset displacements or the selection of a material-specific calibration can be
simply adjusted with the buttons
The menu "Probe Settings" respectively offers the following options:
Setting
Sensor Info
Material Calibration
Offset balancing
Average Mode
Average Parameter
Basic balancing
To reach the probe settings, select the individual probe display mode for the probe intended for
configuration in the measuring display using the
button , the probe setting of the currently used probe is called up.
NOTE:
It is only possible to configure one probe at a time. Should several probes require to be
adjusted, the procedure must be respectively repeated for these other probes.
Attention:
Ensure that the correct probe is set before commencing with adjusting the parameters.
The SONO-VIEW offers the option to access the measuring parameters of the probe. Before adjusting
any parameters, please inform yourself precisely in regard to the function of the same in the respective
probe manual. Any performed changes may affect the measurement value, the accuracy, and the
measuring rate.
12
/ .
Description
Presents information regarding the connected probe
Selection of a material-specific calibration
Displacement of the measurement value
Setting of the method of averaging
Setting of the parameters of the set averaging method
„Zero Value" calibration of the probe in ambient air
/ buttons (also see Item 4.2). By actuating the
