en | Connection
Switch 5 Switch 6
Off On
Off On
On Off
3.2.5 Resetting OSDP-key
To delete the OSDP secure channel data, execute these steps:
1. Power-off the reader (e.g. by disconnecting the reader from the
AMC).
2. Set the reader DIP switches 5 to 8 to OFF.
3. Power-on the reader (e.g. by connecting the reader to the AMC).
4. Wait until the reader continuously flashes the green LED
– The green LED flashing indicates that the OSDP secure
channel data has been deleted.
5. Power-off the reader (e.g. by disconnecting the reader from the
AMC).
6. Set the correct reader DIP switch address ( Configuring the reader
(DIP switches), page 30 ).
7. Power-on the reader (e.g. by connecting the reader to the AMC).
Refer to
– Configuring the reader (DIP switches), page 30
2020-10 | V02 |
Switch 7 Switch 8
On Off
On On
Off Off
LECTUS duo 3000 readers
Address
6
7
8
