- Page 1 PR113B and PR114B Smart Card LAN Reader Security Systems Installer Reference Guide Security System...
- Page 2 Smart Card LAN Readers PR113B - Black and PR114B - White The PR113B and PR114B smart card LAN readers feature a high security, encrypted two way authentication transmission format and can be used to provide alarm and/or access control functionality on selected Solution security control panels.
-
Page 3: Installation
The readers also include an egress input and lock output PR113B & PR114B Mounting Template which can be used to control door access if required. Scale 1:1 Using the on board lock output is not recommend-... - Page 4 LAN readers however it can be turned off via panel programming by setting the reader volume to the lowest level. See the Devices-Keypads & Readers-Commands menu in panel programming. Bosch Security Systems 12/13 PR113B-PR114BIRG FTR1.0...
-
Page 5: Configuration Examples
The egress input triggers the The above examples show how to configure the PR113B lock output on the LAN reader by operating or firing the and PR114B readers to control an area and or a door on associated Access Group or Door Assignment. -
Page 6: Connection Diagram
Address 1. Figure 4: PR113B and PR114B Connection Diagram You must power cycle the panel or perform a LAN scan after connecting the PR113B or PR114B for Note the system to initialise the reader. Bosch Security Systems 12/13 PR113B-PR114BIRG FTR1.0... - Page 7 Compatible Cards, Tokens and Prox Enabled Keypads The PR113B and PR114B readers require the use of our new smart card credentials. Currently the range includes a PR301B keyring token, PR350B ISO card token and the PR365B adhesive token which can be attached to the back of a phone or other device.
- Page 8 Bosch Security Systems 25 Huntingwood Drive Huntingwood, NSW 2148 Australia Phone: +612 9672 1777 Facsimile: +612 9672 1717 © 2013 Bosch Security Systems PR113B-PR114BIRG Issue FTR1.0...
