- Page 1 ARD‑AYK12 Card reader, EM, mini mullion ARD‑AYK12 Installation manual...
-
Page 3: Table Of Contents
ARD-AYK12 Card reader, EM, mini mullion Table of contents | en Table of contents Safety Short Information Introduction FCC compliance Parts included Functional requirements RFID technology Reading distances Installation Before mounting the reader Mounting instructions Assembling the reader 3.3.1 Wiring instructions 3.3.2... -
Page 4: Safety
| Safety ARD-AYK12 Card reader, EM, mini mullion Safety – Read, observe and keep the instructions - the entire safety and operating instructions must be read and correctly followed before the readers are operated. – Take all warnings into account - follow all warnings on the devices and in the operating instructions. - Page 5 ARD-AYK12 Card reader, EM, mini mullion Safety | en Danger! - The device must be operated in a fully assembled state only. - Before connecting the device to the power supply, make sure that the connected operating voltage does not exceed the permitted values according to the technical specifications.
-
Page 6: Short Information
| Short Information ARD-AYK12 Card reader, EM, mini mullion Short Information Introduction This installation manual is aimed at authorized service providers. The installation manual contains instructions on the installation and configuration of the Bosch Security Systems proximity reader ARD-AYK12. -
Page 7: Fcc Compliance
ARD-AYK12 Card reader, EM, mini mullion Short Information | en FCC compliance This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 8: Parts Included
| Short Information ARD-AYK12 Card reader, EM, mini mullion Parts included Make sure that all parts are included and not damaged. If the packaging or any parts are damaged, contact your shipper. If any parts are missing, contact your Sales or Customer Service Representative. -
Page 9: Functional Requirements
ARD-AYK12 Card reader, EM, mini mullion Short Information | en Functional requirements The ARD-AYK12 reader reads data from EM credentials and provides visual and acoustic signals. The reader and the control center communicate through a Wiegand interface. The reader has the following main features: –... -
Page 10: Reading Distances
| Short Information ARD-AYK12 Card reader, EM, mini mullion Reading distances The normal reading distance depends on the respective reading system, the installation environment and the type of data carrier. Direct mounting on metal might reduce the optimal reading distance. -
Page 11: Installation
ARD-AYK12 Card reader, EM, mini mullion Installation | en Installation Before mounting the reader When you choose the installation location, consider the following: – The readers can still interfere with each other at a distance of approximately two or three times the reading distance. - Page 12 | Installation ARD-AYK12 Card reader, EM, mini mullion Determine an appropriate mounting position for the reader. Peel off the back of the self-stick drilling template and place at the desired mounting position. If you do not have the self-stick drilling template, refer to the Drilling Template, page 17 for the dimensions.
-
Page 13: Assembling The Reader
Assembling the reader 3.3.1 Wiring instructions The ARD-AYK12 is supplied with a 45 cm (18 in) pigtail, having a six-conductor cable. To connect the reader to the controller: Prepare the reader cable by cutting the cable jacket back 3.4 cm (11/4 in) and by striping the wires 1.3 cm (1/2 in). -
Page 14: Decommissioning
| Decommissioning ARD-AYK12 Card reader, EM, mini mullion Decommissioning Old electrical and electronic equipment This product and/or battery must be disposed of separately from household waste. Dispose such equipment according to local laws and regulations, to allow their reuse and/or recycling. This will help in conserving resources, and in protecting human health and the environment. -
Page 15: Technical Specifications
ARD-AYK12 Card reader, EM, mini mullion Technical specifications | en Technical specifications Mechanical Dimensions (H x W x D) (in) 3.15 in x 1.57 in x 0.50 in Dimensions (H x W x D) (mm) 80 mm x 40 mm x 13 mm... -
Page 16: More Information
Troubleshooting – Repair & Exchange – Product Security Bosch Building Technologies Academy Visit the Bosch Building Technologies Academy website and have access to training courses, video tutorials and documents: www.boschsecurity.com/xc/en/support/training/ 2024-03 | V02 | Bosch Security Systems B.V. Installation manual... -
Page 17: Appendices
ARD-AYK12 Card reader, EM, mini mullion Appendices | en Appendices Drilling Template CABLE HOLE DIA. 10 mm (7/16 in) Bosch Security Systems B.V. 2024-03 | V02 | Installation manual... - Page 18 | Appendices ARD-AYK12 Card reader, EM, mini mullion 2024-03 | V02 | Bosch Security Systems B.V. Installation manual...
- Page 20 Bosch Security Systems B.V. Torenallee 49 5617 BA Eindhoven Netherlands www.boschsecurity.com © Bosch Security Systems B.V., 2024 Building solutions for a better life 202403011549...
