Tahoe Change Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
5
11
Insert 2 x locking nut (B) into panels [10] . Attach 2 x dowel (C) to panel [10] and
secure with [11]. Insert 2 x bolt (A) into panel [11].
covers (K).
mocka.co.nz | mocka.com.au
K
B
A
10
C
C
K
B
A
Cover locking nuts (B) with 2 x
6
G
3
A
G
E
E
Attach 1 x left slide rail (G) to panel [3] and secure with 2 x small screw (E).
Attach 1 x right slide rail (G) to panel [4] and secure with 2 x small screw (E).
Insert 4 x bolt (A) into panel [3] and [4].
4
A
A
A
G
E
E
Tighten with a screwdriver.
G
4
