11. Accessories

personalize your experience
Bluetooth UV Remote Control
ON/OFF
6 fan speeds
F-RCUV-WT White
Sloped Ceiling Kit
Designed to accommodate buildings with steeper
sloped ceilings up to 45° or 12/12 pitch
XF-SCK
Coupler
Connects two downrods
XF-I
Downrod
XF-12 - 12" Downrod |
XF-24 - 24" Downrod |
XF-48 - 48" Downrod |
XF-72 - 72" Downrod

12. Troubleshooting

My Fan Will Not Start
1. Check main and branch circuit fuses or circuit breakers.
2. Check line wire connections to fan and switch wire connections in
the switch housings.
CAUTION: Make sure the main power is turned off!
24 Ultra Smart Fan Instructions
XF-18 - 18" Downrod
XF-36 - 36" Downrod
XF-60 - 60" Downrod
F R - D 21 0 2

12. Troubleshooting cont.

My Fan is Noisy
1. Allow for 24-hour break-in period. Most noises associated with a
new fan will go away during this time period.
2. Check to make sure the screws which attached to the blades
(and blade arms when applicable) are tight.
3. Check to make sure all screws in motor housing are snug.
4. Tighten the hanger bracket screws and make sure the outlet box
is secured.
5. Your wire connectors may be rattling against the fan's canopy.
6. Make sure you have a cUL/UL approved outlet box and it is
installed correctly.
My Fan is Wobbling
1. Tighten the set screws in the downrod.
2. Make sure your hanger ball assembly is locked into place in the
hanger bracket.
3. Tighten the hanger bracket screws to the outlet box.
4. Make sure the fan blades are properly aligned and securely
fastened to the motor housing assembly/blade arms.
5. Make sure the gaps between the blades are evenly distributed or
make sure you are using an approved cUL/UL listed outlet box
and it is installed correctly.
My Fan is not producing Enough Air Movement
If possible, please consider using a longer than included downrod.
F R - D 2 1 0 2 Ultra Smart Fan Instructions 25
