Add I/Os

Adding I/O devices not only increases the number of I/O channels, but lets you have separate devices for stage and
FOH, or live room and control room. When there is more than one network connection, use a "star" network configuration
with a 1GB Ethernet switch. Only use switches tested and approved by Waves.
You can connect and assign up to 16 SoundGrid I/O devices to the network, depending on the SoundGrid Host
Application. You can also add more computers to enable audio streaming between hosts.
A S
DD A ERVER
To add a server to your SoundGrid system, just connect it to the Ethernet switch and configure it in your host application.
This moves all DSP processing from the host computer to the server, which provides a higher plugin count and enables
the eMotion LV1 and ST mixers. Visit the
your SoundGrid host application's user guide to learn about using servers.
7
waves.com hardware pages to learn more about SoundGrid servers. Consult
Host computer
MADI-enabled console or device
MGR
One or more SoundGrid I/O devices
1GB Ethernet switch
See this support article for a list of
supported switches.
