Add I/Os

Adding I/O devices not only increases the number of I/O channels, but lets you have separate devices for stage and
FOH, or live room and control room. Use a "star" network configuration with a 1GB Ethernet switch to connect SoundGrid
devices. Only use switches tested and approved by Waves.
You can connect and assign up to 16 SoundGrid I/O devices to the network, depending on the SoundGrid host
application. All SoundGrid I/O devices, hosts, and servers are connected through the Ethernet switch. You can also add
more computers to enable audio streaming among hosts.
A S
DD A ERVER
To add a server to your SoundGrid system, just connect it to the Ethernet switch and configure it in your host application.
This moves all DSP processing from the host computer to the server, which provides a higher plugin count and enables
the eMotion LV1 and eMotion ST mixers. Visit the
Consult your SoundGrid host application's user guide to learn about using servers.
Consult your host application user guide to learn how to configure additional I/Os and servers.
7
Host computer
I/O devices
1GB Ethernet switch
See this support article for a list of supported switches.
waves.com hardware pages to learn more about SoundGrid servers.
