WattAge WILD CAT 400 EP Instructions For Final Assembly

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
I N S T R U C T I O N S F O R F I N A L A S S E M B LY
The Wattage Wild Cat 400 EP ARF is distributed
exclusively by Global Hobby Distributors
18480 Bandilier Circle, Fountain Valley, CA 92708
All contents copyright © 2003, Global Hobby
Distributors Version V1.0 July 2003
Kit Product Number 128398
IMPORTANT
The Wattage Wild Cat 400 EP ARF is not intended for inexperienced pilots. It is in no way a trainer. If
you are not comfortable flying aerobatic sport aircraft, we strongly suggest returning the Wild Cat 400 EP ARF (brand
new, in the box with all original packaging) to the place of purchase.
Visit our website at http://watt-age.globalhobby.com for information on other Wattage products
Specifications:
Wing Span: 36 Inches
Wing Area: 305 Square Inches
Length: 33.5 Inches
Weight RTF: 29 - 32 Ounces
Wing Loading: 13.75 - 15 Ounces Per Square Foot
Functions: Ailerons, Elevator, Rudder & Throttle
Power: Cobalt 400 Direct Drive w/7 x 4 Propeller
Radio Required: 4Ch or More Micro w/3 Micro Servos
ESC Required: 30 Amp Micro
Battery Required: 7 Cell CP1300 SCR
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WILD CAT 400 EP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WattAge WILD CAT 400 EP

Summary of Contents for WattAge WILD CAT 400 EP

  • Page 1 IMPORTANT The Wattage Wild Cat 400 EP ARF is not intended for inexperienced pilots. It is in no way a trainer. If you are not comfortable flying aerobatic sport aircraft, we strongly suggest returning the Wild Cat 400 EP ARF (brand new, in the box with all original packaging) to the place of purchase.

  • Page 2: Table Of Contents

    In no case shall Wattage's liability exceed the original cost of the purchased kit. In that Wattage has no control over the final assembly or material used for final assembly, no liability shall be assumed for any damage resulting from the use by the user of the final user-assembled product.

  • Page 3: Introduction

    INTRODUCTION Thank you for purchasing the new Wattage Wild Cat 400 EP ARF. Before completing the final assembly of your new airplane, please carefully read through this instruction manual in its entirety. Doing so will ensure your success the first time around!

  • Page 4: Section 1: Our Recommendations

    This section describes our recommendations to help you in deciding which types of accessories to purchase for your new Wild Cat 400 EP ARF. Please read through this entire section very carefully. We have provided you with tips and recommendations that, if followed, will result in a great flying airplane. Failure to follow our recommendations may result in a poor flying airplane.

  • Page 5: Section 2: Tools And Supplies Required

    The part number listed for the Hitec 555 Micro receiver is compatible with Hitec radio control systems. This receiver is also available for Futaba, JR and Airtronics radio control systems. The Wattage IC-30A Micro ESC is compatible with Futaba, JR, Hitec, Airtronics-Z and others.

  • Page 6: Section 3: Kit Contents

    To convert millimeters into inches: Millimeters / 25.4 = in We stock a complete line of replacement parts for your Wattage Wild Cat 400 EP ARF. Please refer to page # 29 for more details and a replacement parts list.

  • Page 7: Section 4: A Note About Covering

    SECTION 5: BECOMING FAMILIAR WITH YOUR COBALT 400 MOTOR Your Wattage Wild Cat 400 EP ARF is powered by the Wattage Super Cobalt 400 Direct Drive motor. This motor is a high-quality alternative to lower powered, closed end-bell motors, and more expensive specialty motors. The Super Cobalt 400 Direct Drive motor features a 3.2mm (1/8") shaft and a bolt pattern that can match either 05 or 400 size...

  • Page 8: Section 6: Breaking In The Super Cobalt 400 Motor

    SECTION 6: BREAKING IN THE SUPER COBALT 400 MOTOR Taking time to break in the motor now will result in increased motor performance and longevity. You can either secure the motor to the fuselage during the break-in process or you can secure the motor to a test stand. If you secure the motor to the fuselage, make sure to hold the fuselage securely during the break-in process.

  • Page 9: Section 7: Stabilizer Installation

    M3 flat washer. STEP 2: ALIGNING THE HORIZONTAL STABILIZER Using a builder's triangle and a pencil, carefully measure and draw a vertical centerline across the top of the stabilizer. Visit our website at http://watt-age.globalhobby.com for information on other Wattage products...
  • Page 10 Slide the stabilizer into the mounting slot and temporarily align it. The stabilizer should be pushed forward completely and, when viewed from above through the vertical stabilizer mounting slot, the centerline you drew on top of the stabilizer should be centered with the back of the fuselage. IMPORTANT When the stabilizer is slid into place, make sure that the back of the fuselage is not closed up.
  • Page 11 With the stabilizer in place and aligned, use a builder's triangle to check and make sure that the vertical stabilizer is aligned 90º to the horizontal stabilizer. Visit our website at http://watt-age.globalhobby.com for information on other Wattage products...

  • Page 12: Section 8: Hinging The Control Surfaces

    While holding the vertical stabilizer firmly in place, use a pencil to draw a line on each side of the stabilizer where it meets the top of the fuselage. Remove the stabilizer from the fuselage. Using a modeling knife, carefully cut away and remove the covering material from below the lines you drew.

  • Page 13: Section 9: Landing Gear Installation

    Using 220 grit sandpaper with a sanding block, sand the edges of the plastic mount smooth and straight. Visit our website at http://watt-age.globalhobby.com for information on other Wattage products...
  • Page 14 Position the landing gear wire and plastic mount onto the bottom of the fuselage. When aligned correctly, the back edge of the plastic mount should be even with the front of the wing saddle and centered between the fuselage sides. When satisfied with the alignment, remove the landing gear wire and the plastic mount.

  • Page 15: Section 10: Motor & Cowling Installation

    STEP 1: INSTALLING THE MOTOR Using a 5/64" hex wrench, remove the propeller adapter from the motor and set it aside. IMPORTANT The propeller adapter must be removed to install the motor. Visit our website at http://watt-age.globalhobby.com for information on other Wattage products...
  • Page 16 Slide the motor into position and line up the holes in the front of the motor with the slot in the motor plate. Secure the motor into place using two M3 x 8mm machine screws and two M3 flat washers. Tighten the screws firmly to hold the motor securely into place.

  • Page 17: Section 11: Control Systems Installation

    When satisfied with the alignment, mark and drill 5/64" diameter pilot holes through the elevator half for the control horn mounting screws. Visit our website at http://watt-age.globalhobby.com for information on other Wattage products...
  • Page 18 IMPORTANT Before installing the control horn in the next procedure, apply several drops of thin C/A into the holes and allow the C/A to fully cure. The C/A will harden the surrounding balsa, making the mounting area stronger. Install the control horn and backplate using two M2 x 12mm machine screws, being careful not to overtighten them. Repeat the previous procedures to install the second control horn and backplate onto the other elevator half.
  • Page 19 Remove the masking tape from the rudder and double-check that the servo horn and the rudder are still centered. If the rudder is not centered, adjust the clevis until the rudder is centered. Visit our website at http://watt-age.globalhobby.com for information on other Wattage products...
  • Page 20 STEP 3: INSTALLING THE AILERON CONTROL SYSTEM Using 220 grit sandpaper with a sanding block, sand the edges of the aileron servo tray smooth and straight. Using a modeling knife, cut a small hole in the top of the wing, directly above the aileron servo cutout, just large enough for the aileron servo lead to fit through.

  • Page 21: Section 12: Final Assembly

    For a more realistic appearance, carefully paint the pilot bust using your favorite colors. This takes some time, but really dresses up the airplane. To dress up the cockpit, you can paint the inside of the cockpit flat black, too. Visit our website at http://watt-age.globalhobby.com for information on other Wattage products...
  • Page 22 Using a pair of scissors, carefully cut the front and back of the pilot bust to fit over the elevator and rudder servos. We cut the pilot bust so that when the pilot was installed, the base of the pilot was about 1/4" off the cockpit floor. This prevents having to cut all the way through the top of the pilot.
  • Page 23 Position the fairing onto the wing, as shown. The sides of the fairing should be even with the sides of the fuselage and there should be a 1/16" gap between the front of the fairing and the fuselage. Visit our website at http://watt-age.globalhobby.com for information on other Wattage products...

  • Page 24: Section 13: Balancing The Wild Cat 400 Ep Arf

    C/G back farther than 1/4" behind the main spar. Balance the Wild Cat 400 EP ARF with the flight battery installed. Turn the airplane upside down, place your fingers over the main spar (at the fuselage sides), and carefully lift the airplane.

  • Page 25: Section 14: Lateral Balancing The Wild Cat 400 Ep Arf

    SECTION 15: CONTROL THROWS We recommend setting up the Wild Cat 400 EP ARF using the control throws listed below. These control throws are suggested for initial test-flying because they will allow the airplane to fly smoother and make it easier to control.

  • Page 26: Section 16: Preflight Check & Safety

    SECTION 16: PREFLIGHT CHECK & SAFETY Check the operation of the throttle. To do this, do the following: A) Plug the flight battery into the ESC and turn on the radio system. WARNING Do not turn the receiver on unless the transmitter is turned on first. Always turn the transmitter on first. Never allow hands or clothing to get in the way of the propeller when the radio is turned on.

  • Page 27: Section 17: Flying The Wild Cat 400 Ep Arf

    SECTION 17: FLYING THE WILD CAT 400 EP ARF The Wild Cat 400 EP ARF is designed for those pilots who are experienced at flying sport models. It is not a trainer. If you do not feel comfortable about test-flying the airplane, don't hesitate to ask someone more experienced for help.

  • Page 28: Section 18: Wild Cat 400 Ep Trim Chart

    SECTION 18: WILD CAT 400 EP TRIM CHART After you have test-flown and done the initial trim changes to the airplane, use this trimming chart to begin trimming your airplane. Following and adhering to this chart will result in the ability to diagnose trim problems and correct those problems using the simple adjustments shown below.

  • Page 29: Section 19: Replacement Parts

    We suggest ordering directly from your local dealer. If your dealer does not stock Wattage products, you can order directly from us at the address shown below:...
  • Page 30 Need help or have any questions? Call us at 1-714-963-0329 or send us an email to service@globalhobby.net...

  • Page 31: Product Evaluation Sheet

    2 - 4 5 - 7 8 - 10 10 or More Please List any Other Modeling Interests or any Additional Information about This Product: ______________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ _____________________________________________________________________________________ Visit our website at http://watt-age.globalhobby.com for information on other Wattage products...
  • Page 32 _____________________________ _____________________________ Post Office will not deliver _____________________________ without proper postage (Return Address Here) Global Hobby Distributors Attn: Global Services 18480 Bandilier Circle Fountain Valley CA 92728-8610 Fold along dotted line Need help or have any questions? Call us at 1-714-963-0329 or send us an email to service@globalhobby.net...
