Package Contents
1. Blade Set of 3
RPL-F2102-54-BD-**
2. Hanger Assembly -
Mounting Bracket
Downrod Assembly
RPL-HGR-ASM-10-**
(optional 6" rod included for closer to ceiling
mount applications)
3. Canopy & Canopy
Screw Ring
RPL-CAN-CYL-**
4. Coupling Cover
RPL-COU-CVR-**
** Denotes finish code of fan
1
If you need a replacement tray - please order part no. RPL-F-UV7INTRAY-**
2
If you need a replacement UV module - please order part no. UVF7IN-120V-R1-MOD
Contact fansupport@modernforms.com if you need glass fixing plates, silicone rings, or hardware
Hardware Bag
RPL-F2102-PARTS
• Part A
• Part B
• Part C
• Part D
Before discarding packaging materials be certain all parts have been removed.
Place the parts from the hardware bag into a small container to keep them from being lost.
8 Ultra Germicidal Smart Fan Instructions
5. Motor Assembly
5A.
6. Aluminum Tray
RPL-F-UV7INTRAY-**
(UV Module not included)
5B.
UV Module
UVF7IN-120V-R1-MOD
6.
7. Control Receiver
w/Hardware
F-R3-2102-054
7. 8. Remote w/Wall Cradle
F-RCUV-WT
Hardware Bag
RPL-F2102-PARTS
#10 x 38mm Pan Head Phillip Screws (2)
5 x 14 x 1mm Flat Washer (2)
3/16" Star Washer (2)
B: Blade Screw / Washers
3/16 *6mm Philip Washer Head Screws (10)
5.5x12x1mm Flat Washer (10)
1
2
6.5x19x2mm Flat Washer (1)
3/16"( 5.2x8.4x1.0mm) Spring Washer (1)
#10x76mm Pan Head Phillip Wood Screws (1)
(8)
(Found with the receiver)
F R - D 2 1 0 2
