4. Hanging the Fan cont.

5. Align the holes of the downrod and collar and insert the cotter
pin and clevis pin. Tighten the two collar screws. (Fig 4B)
6. Slip the coupling cover, canopy screw ring (painted side down),
and canopy (opened side up) onto the downrod. (Fig. 4B)
7. Reinstall the hanger ball onto the downrod, being sure that the
cross pin is in the correct position and the screw is tightened.
(Fig 4B)
WARNING:
the set screws could result in the fan loosening and possibly falling.
NOTE: Make sure all screws are tightened and that wires
are not twisted.
8. Carefully lift the fan motor assembly up to the mounting bracket
and seat the hanger ball in the mounting bracket socket. Make
sure the tab on the mounting bracket socket is properly seated
in the groove in the hanger ball. Rotate the socket assembly until
the ball drops and locks into the hanger bracket screw. (Fig. 4C)
9. Secure the safety cable into the structure beams using the wood
screw, washers, and spring washers provided (Fig. 4D).
NOTE: A Safety cable is required for all installations in Canada.
Safety cable is required for ceiling fan and light combinations over
35 lbs. in both flush and downrod models in the United States. Use
Part C.
14 Ultra Germicidal Smart Fan Instructions
Failure to properly install the cotter pin and/or tighten
F R - D2 1 0 2
