Summary of Contents for J&M 206270
- Page 1 Hydraulic Talc I n s t a l l a t i o n K i t Serial Number 206270 and Higher J&M Manufacturing Co, Inc 284 Railroad Street - P.O. Box 547 | Fort Recovery, OH 45846 | Ph: (419) 375-2376 | Fax: (419) 375-2708...
-
Page 3: Table Of Contents
Table of Contents 4 ..................To the Dealer 5 . -
Page 4: To The Dealer
To the Dealer Read manual instructions and safety rules. Make sure all items on the Dealer’s Pre-Delivery and Delivery Check Lists are completed before releasing equipment to the owner. The dealer must complete the Warranty Registration found on the Dealer Portal website located at dealer.jm-inc.com and return it to J&M Mfg. -
Page 5: General Information
General Information TO THE OWNER: The purpose of this manual is to assist you in operating and maintaining your Talc Applicator in a safe manner. Read it carefully. It furnishes information and instructions that will help you achieve years of dependable performance and help maintain safe operating conditions. -
Page 6: Safety Rules
Safety Rules ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! Safety is a primary concern in the design and manufacture of our products. Unfortunately, our efforts to provide safe equipment can be erased by an operator’s single careless act. In addition, hazard control and accident prevention are dependent upon the awareness, concern, judgment, and proper training of personnel involved in the operation, transport, maintenance and storage of equipment. -
Page 7: Talc Box Mount Assembly
Talc Box Mount Assembly STEP ONE - LC 290 & LC 390 • Bolt the LC 290/LC 390 talc box mounting bracket (JM0037272) to the SpeedTender’s front passenger side leg using two 3/8” x 1” flange bolt and 3/8” flange nuts. Hand tighten fasteners. •... -
Page 8: Flex Flighting Assembly
Flex Flighting Assembly STEP ONE - SpeedTender Pro c4·50 • Bolt the SpeedTender Pro c4·50 talc box mounting bracket (JM0037645) to the SpeedTender’s front passenger side leg using four 3/8” x 1” flange screws and 3/8” flange nuts. Hand tighten fasteners. •... -
Page 9: Attaching Motor And Door Skirt
Attaching Motor and Door Skirt Install and tighten the 10-32 x 1/4” Cup-Point Set Screw once 1/4"-28 x 3/8" Gr5 Z Hex Bolt the motor is in place. 1/4"-20 x 3/4" Gr5 Z SF Hex Bolt 1/4"-20 Gr5 Z SF Hex Nut STEP THREE - All models •... -
Page 10: Talc Pvc Tube Assembly
Talc PVC Tube Assembly STEP SIX - LC 290, LC 390 & SpeedTender Pro c4·50 • Attach the talc flighting PVC tube (LC 390 - JM0042810, LC 290 - JM0042809, SpeedTender Pro c4·50 - JM0043049) over the fighting with the 2” exhaust clamp. (JM0037668) •... -
Page 11: Assembly For Aluminum Valve
Assembly for Aluminum Valve If you have a Black Intercomp Valve go to “Assembly For Black Intercomp Valve” on page 13. If you have an Aluminum Valve, continue with the following instructions: STEP SEVEN - All models • Mount the flow control valve (JM0026104) using the flow control mounting bracket (LC 290/LC 390/SpeedTender Pro c4·50-JM0043097, LC 535-JM0025400). - Page 12 Assembly for Aluminum Valve STEP NINE - All models • Route the talc motor hydraulic hoses (JM0042861) through the conduits on the trailer as shown below. Tighten the hoses to the flow control valve and hydraulic talc motor. Hoses go straight to valve bank. Seth LC 290/LC 390 SpeedTender Pro c4·50...
-
Page 13: Assembly For Black Intercomp Valve
Assembly For Black Intercomp Valve The black intercomp valve bank is shown on the left. Black Intercomp Valve Bank STEP SEVEN- All models • Remove the two 90° hydraulic fittings on the right side shown on the left. STEP EIGHT - All models •... -
Page 14: Hydraulic Schematic And Repair Parts For Black Intercomp Valve With Talc
Hydraulic Schematic and Repair Parts for Black Intercomp Valve with Talc 13 14 Description Part No. 3/8” Male JIC x 3/8” Male ORB; Extra Long 90 Degree Elbow (6801-LL-06-06) JM0039050 3/8” Male JIC x 3/8” Male ORB; 90 Degree Elbow JM0026121 White Drive Hydraulic Motor - 125032JL5C3AAAAA JM0042491... -
Page 15: Hydraulic Schematic And Repair Parts For Aluminum Valve Bank With Talc
Hydraulic Schematic and Repair Parts for Aluminum Valve Bank with Talc Hydraulic Motor Aluminum Valve Bank c4•50 Model Conveyor Return Hose Flow Control To Conveyor Return Hose Description Part No. 3/8” Male JIC x 3/8” Male O-ring; Extra Long 90 Degree Elbow (6801-LL-06-06) JM0039050 3/8”... -
Page 16: Talc Parts For Lc 290, Lc 390
Talc Parts for LC 290, LC 390 11 10... - Page 17 Talc Parts for LC 290, LC 390 Description Part No. 3/16” Nylon Rod for Talc Agitator JM0062689 3/4” Shoulder Dia x 1” Shoulder Length x 5/8”-11 Hex Head Shoulder Bolt and Nut (SB-34) JM0003181 3/4” ID x 7/8” OD x 5/8” LG Bronze Bushing (BB-34) JM0009455 Large Talc Box Screen (Electric &...
-
Page 18: Talc Parts For Lc 535 Speedtender
Talc Parts for LC 535 SpeedTender 11 10 25 26... - Page 19 Talc Parts for LC 535 SpeedTender Description Part No. 3/16” Nylon Rod for Talc Agitator JM0062689 3/4” Shoulder Dia x 1” Shoulder Length x 5/8”-11 Hex Head Shoulder Bolt and Nut (SB-34) JM0003181 3/4” ID x 7/8” OD x 5/8” LG Bronze Bushing (BB-34) JM0009455 Large Talc Box Screen (Electric &...
-
Page 20: Talc Parts For C4•50
Talc Parts for c4•50 11 10 Hydraulic Valve Mount... - Page 21 Talc Parts for c4•50 Description Part No. 3/16” Nylon Rod for Talc Agitator JM0062689 3/4” Shoulder Dia x 1” Shoulder Length x 5/8”-11 Hex Head Shoulder Bolt and Nut (SB-34) JM0003181 3/4” ID x 7/8” OD x 5/8” LG Bronze Bushing (BB-34) JM0009455 Large Talc Box Screen (Electric &...
