Installing an IB850 Log Template

G0200

Step 1:

Lift off the inner fascia by pulling

the base of inner fascia out and

lifting it up and off.

Step 2:

Unscrew the top glass

retainer and remove it. Take

care that the glass does

not fall forwards at this

stage.

Step 3:

Lift out glass and place it carefully

aside.

Step 4:

Take out log set and gently brush any

soot from log with a soft hearth brush.

The burner tops can be vacuumed to

remove any excess material.

Step 6:

Install the Log Template as per instructions

on the opposite page.

Table of Contents

Do you have a question about the IB850 and is the answer not in the manual?

Page 1 Installing an IB850 Log Template G0200 Removing the log set and glass: Step 1: Lift off the inner fascia by pulling the base of inner fascia out and lifting it up and off. Step 2: Unscrew the top glass retainer and remove it. Take...
Page 2 To attach the Log Template at the left hand side, use the existing screw which is holding the middle burner in place. Remove this screw and re-attach with the log bracket in place. To attach to the right hand side, use the supplied screw and brass washer as shown in the diagrams below.
