Square (Quadrato) Fascia - IB850, IB1100

Installation Manual

AUSTRALIAN EDITION

Important:

The appliance shall be installed in accordance with;

• This installation instruction booklet.

• Must be installed by a qualified person

• This Manual replaces section 23.0 of the IB Series Installation Manual

This appliance is not intended for use by young children or infirm persons unless they have been

adequately supervised by a responsible person to ensure that they can use the appliance safely.

Young children should be supervised to ensure that they do not play with the appliance.

Manufactured by: Escea Ltd, PO Box 5277 Dunedin NZ, Ph: +64 3 479 0302, email: info@escea.com.au

For contact details of your local escea distributor or dealer please visit

www.escea.com.au

630099_4 Square Fascia Installation Manual AUS.docx

Need help?

Do you have a question about the Square (Quadrato) Fascia IB850 and is the answer not in the manual?

Page 1 Young children should be supervised to ensure that they do not play with the appliance. Manufactured by: Escea Ltd, PO Box 5277 Dunedin NZ, Ph: +64 3 479 0302, email: info@escea.com.au For contact details of your local escea distributor or dealer please visit www.escea.com.au...
Page 2 Fitting the Square Fascia Panels: To avoid scratches or knocks to the fascia panels of this gas fireplace they must be fitted at the complete conclusion of the installation process. It may be necessary to use the Outer Fascia to initially locate the gas fireplace but then remove it again so that there is no chance of damage.
Page 3 Step 3: Remove Existing Bracket The next step in attaching the square fascia mounts, is to remove the existing left hand fascia bracket attached to the control box on the front left hand side of the firebox. Using a screwdriver, carefully screw out the two screws holding the left hand bracket in place. Remove this bracket.
Page 4 Step 5: Attach the Inner Fascia Brackets to the bottom of the Inner Fascia (smaller one) as per the diagram supplied with the Inner Fascia. Hang the top edge of the Inner Fascia from the lip that extends at 45 degrees from the top of the firebox.
