7.2.1 J2 – BT.656 Video Output
KEL USL00-30L
Pin No. Name
1 GND
2 IRQ#_1V8
3 DATA_1V8_0
4 HSYNC_1V8
5 I2C_SDA_1V8
6 I2C_SCL_1V8
7
DATA_1V8_1
8
DATA_1V8_3
9
VSYNC_1V8
10
GND
11
DATA_1V8_2
12
DATA_1V8_11
13
DATA_1V8_9
14
CLKOUT_1V8
15
DATA_1V8_12
16
DATA_1V8_10
17
DATA_1V8_15
18
N/C
19
DATA_1V8_13
20 DATA_1V8_6
21 DATA_1V8_5
22 N/C
23 RESET#_1V8
24 DATA_1V8_7
25 DATA_1V8_4
26 DATA_1V8_8
27 DATA_1V8_14
28 GND
29 5V IN
30 5V IN
Comments
