Installation Instruction
V1.0
PSFS01
Thank you for choosing our product! We strive to provide the best
quality and services for our customers. Would you kindly share your
experience on Amazon if you are satisfied? Should you have any
issues, please don't hesitate to contact us.
Telephone：800-5566-806 Mon-Fri 10am - 6pm (PST) (USA) (CAN)
Email：supportus@perlesmith.com (US/CA/DE/UK/FR/IT/ES/JP/AU)
Advertisement
Table of Contents
Related Manuals for Perlesmith PSFS01
Summary of Contents for Perlesmith PSFS01
- Page 1 Installation Instruction V1.0 PSFS01 Thank you for choosing our product! We strive to provide the best quality and services for our customers. Would you kindly share your experience on Amazon if you are satisfied? Should you have any issues, please don't hesitate to contact us.
- Page 2 Not all parts and hardware included will be used. lf you require replacement • parts, contact customer service at supportus@perlesmith.com This product may contain moving parts. Use with caution. • •Please check www.perlesmith.com for more products and company information. Supplied Parts List Support Pillar Tempered Glass...
- Page 3 Connecting the Support Pillar to Tempered Glass Step 1 Tempered Glass (Painting Side) Rubber Pad Support Pillar Plastic Socket Allen Key Connecting the TV Plate to Support Pillar Step 2 Allen Key two choices for height adjustment for the wall plate M6x60 Bolt TV Plate Metal Pad...
- Page 4 Wire Clip Step 3 Measure VESA and Check TV screws Measure the distance between the holes located at the back of your TV (these measures may form the shape of a square, or a rectan-gle) and check that these taken measures are within the When attaching brackets to the flat VESA(*) range for this wall screen, be careful not to over tighten...
- Page 5 Step 4 Mounting the Monitor Bracket to a TV screwdriver(Not included) TV1,4 FLAT BACK TV (UNIVERSAL MONITOR PLATE) ROUND BACK TV TV2,3,5,6 (UNIVERSAL MONITOR PLATE) TV7,8 First, make sure the diameter of the bolt(TV1-6) fits your TV. Then, please see the diagram above. You will need to thread the bolt into the TV using the correct washer (TV9) and spacer (TV7 or TV8) if necessary with a screwdriver(Not included).
- Page 6 Swivel Adustment Adusting the Height of the TV Step 6 Height adjustable vertical bracket(4) first choice second choice third choice If you find your TV set is too close to the base, please take off the TV from the stand. Then, change to the second choice or third choice to allow more space between TV and the tempered glass base (3).
