H1/6 VIOLET
This wire is used in vehicles that have a positive (+) switched domelight
circuit . Connect the violet wire to a wire that shows (+)12V when a
door is opened, and ground when the door is closed. This wire reports
Zone3.
H1/7 BLUE
This wire responds to a negative input with an instant trigger. It is ideal
for hood and trunk pins, and reports on Zone1.
H1/8 GREEN
Most vehicles use negative door trigger circuits. Connect the green
wire to a wire which shows ground when any door is opened. In
vehicles with factory delays on the domelight circuit, there is usually a
wire that is unaffected by the delay circuitry.
© 2008 Directed Electronics All rights reserved.
(+) DOOR TRIGGER INPUT
(-) INSTANT TRIGGER INPUT (ZONE 1)
(-) DOOR TRIGGER INPUT
