BWT AQA Detector: Quick guide

Installation of the AQA Detector (EN)

1. The AQA Detector box must be taken apart – remove the back.
Use the part with the PCB.

2. Connect 12V power supply

Do not connect the power
a. Connect 12V power supply to the terminals marked POWER in the AQA
Detector box.
b. Lead the cable through the cable gland to the right.
c. The wire with white stripes shall be connected to "+" and the black wire to "-".
See page 3.

3. Connect the solenoid Valve

See the installation guide on the solenoid valve EV228BW
a. Connect the solenoid valve to the terminals marked "VALVE" in the AQA
Detector box.
b. Cut off the earth wire (yellow/green)
c. Lead the cable through the cable gland in the middle. The blue wire is to be
connected to "0" and the brown wire to "C". See page 3.

4. Connect the AQA Stop Floor Sensor

a. Connect the AQA Stop Floor Sensor to the terminals marked "SENSOR" in the
AQA Detector box.
b. Lead the cable through the cable gland to the left.
c. The yellow wire shall be fitted at the left side of the terminal and the white wire
shall be fitted at the right side of the terminal. See page 3.
