Series
Model Selection 3
Note)
Table Deflection
Table deflection due to pitch moment load
F
A
M F x L
1 =
CYV15 (M )
1
0.05
0.04
0.03
0.02
0.01
0 0.1 0.2
Moment (N⋅m)
CYV32 (M )
1
0.05
0.04
0.03
0.02
0.01
0 0.5 1
Moment (N⋅m)
Vertical Operation
When using in vertical operation, prevention of
work piece dropping due to breaking of the
magnetic coupling should be considered. The
allowable load mass and maximum operating
pressure should be as shown in the table below.
Allowable load mass
Model operating pressure
mv (kg)
CYV15 1
CYV32 5
CYV
Design Parameters 2
Table deflection due to roll moment load
CYV15 (M
2
0.05
0.04
0.03
0.02
0.01
0.3 0
CYV32 (M
2
0.05
0.04
0.03
0.02
0.01
1.5 2 0
Intermediate Stops
The cushion effect (smooth start-up, soft stop) is applied only before the stroke end in the stroke ranges
indicated in the table below.
The cushion effect (smooth start-up, soft stop) is not available an intermediate stop or return from an
intermediate stop using an external stopper, etc.
When using an intermediate stop with the above information taken into account, implement measures to
prevent particulate generation and set the operating pressure to no more than 0.3MPa.
Maximum
Cushion stroke
Pv (MPa)
Model
0.3
CYV15
CYV32
A F
L
Central axis of guide
M F x L
2 =
)
0.1 0.2 0.3
Moment (N⋅m)
)
0.5 1 1.5 2
Moment (N⋅m)
Stroke
(mm)
25
30
Table deflection due to yaw moment load
Central axis of guide
F
A
M F x L
3 =
Note) Deflection: Displacement of point A when
force acts on point F
Point A: Indicates a measurement point
CYV15 (M )
3
0.05
0.04
0.03
0.02
0.01
0 0.1 0.2
Moment (N⋅m)
CYV32 (M )
3
0.05
0.04
0.03
0.02
0.01
0 0.5 1
Moment (N⋅m)
0.3
1.5 2
