1
Rodless Cylinder for Vacuum
Series
Rodless cylinder
for vacuum

Specifications

Bore size (mm)
Operating environment pressure
Operating atmosphere
Fluid
Action
Proof pressure
Operating pressure range
Leakage
Maximum baking temperature
Ambient and fluid temperature
Piston speed
Stroke adjustment
Cushion
Port size
Lubrication
Weights
Model
CYV15
CYV32
Magnet Holding Force
Bore size (mm)
15
32
CYV

How to Order

CYV 15 200
Bore size
15 15mm
32 32mm
15
Atmosphere to 1.3 x 10
(at normal temperatures, excluding gas permeation)
-2 to 0mm on each side (-4 to 0mm total)
5/16-24UNF
Vacuum grease for linear guide unit
Standard stroke (mm)
100 150 200 250 300
1.2 1.4 1.6 1.7 1.9
4.2 4.6 5.0 5.5 5.9
Theoretical Output
Magnet holding
Bore size
force (N)
(mm)
59
15
268
32
Standard stroke
Bore size (mm) Standard stroke (mm)
100, 150, 200, 250
15, 32 300, 350, 400, 450
500, 600, 700
32
- ⁴
Pa (ABS)
Air and inert gases
Air and inert gases
Double acting
0.5MPa
0.05 to 0.3MPa
⁷ Pa⋅m³/sec or less
-
1.3 x 10
150°C
-10 to 60°C
50 to 300mm/s
Sine cushion (Air cushion)
7/16-20UNF
and inside the cylinder tube
350 400 450 500 600
2.0 2.2 2.4 2.5 2.8
6.3 6.7 7.1 7.5 8.3
Operating pressure
Piston area
(MPa)
(mm²)
0.1 0.2
18 35
176
804 80 161
(kg)
700
3.2
9.1
(N)
0.3
53
241
