2 General Information

2.1 General information service record

All individual settings, adjustments, repairs and the annual inspection of the wheelchair are
described below. This requires tools and special expertise. Please leave these adjustments to a
qualified specialist retailer.
Adjustments that can be made by the attendant are described in the instructions for use.
If you have any questions or comments, please contact your specialist retailer or our team (+49
7254 9279-0).

2.2 Documentation indications

Please note:
Information for the user can be found in the instructions for use
Maintenance instructions can be found under: Chapter 4 (Repairs & Maintenance)

2.3 Required torques and tools

Torque required for the following screws:
M5: 5 Nm;
M6: 7 Nm;
M6 (perforated plate) 10 Nm
M8: 20 Nm;
M10 (nut): 25 Nm; (caster wheel)
thru axle fitting 40 Nm
Needed tools:
Torque wrench (5-50 Nm)
Open-ended wrench
Reversible ratchet with socket wrench inserts
Hexagon screwdriver
Phillips screwdriver
Flat-blade screwdriver
Plastic hammer
Side cutter
Thread locking liquid
Bicycle tube repair kit
Workbench / vice with plastic jaws
Special open-end wrench for adjusting the shock absorber
2021-05-26
Service record Dynamis TSD
5 of 36
