Appendix A. Schematics
The PIC32MZ DA Family Starter Kit schematics are as follows:
• PIC32MZ2064DAx288 Daughter Card
• PIC32MZ2064DAx169 Daughter Card
• PIC32MZ DA SK Base Board
• LAN8740 PHY Daughter Card
(Figure A-1 through
(Figure A-5 through
(Figure A-8 through Figure
(Figure A-13)
Schematics
Figure A-4)
Figure A-7)
A-12)
DS70005311A-page 27
