The top assembly of the PIC32MZ2064DAx288 Daughter Card includes these key

features, as indicated in

Figure

1. PIC32MZ2064DAA288 (DM320008) or PIC32MZ2064DAB288 (DM320008-C)

(U1).

2. Micron 1 Gbit DDR2-SDRAM (MT47H64M16NF-25E) (U3).

3. 24 MHz oscillator (Y1).

4. 24 MHz crystal (Y3) and 32.768

Note:

Y2 and Y3 are 'Do Not Populate' (DNP).

5. 1.8V Regulator (power supply for DDR2-SDRAM, V

(MIC69101) (J7).

6. 3.3V Power LED (LD2).

FIGURE 1-4:

PIC32MZ2064DAx288 DAUGHTER CARD LAYOUT

(TOP VIEW)

1-4.

Hz clock (Y2).

DDR1V8

Introduction

and V

)

DDCORE

DS70005311A-page 17
