SV9000 AF Drives — Motor Pump Enhanced Protection Application
Application Manual
June 2004
Supersedes February 2001
MN04001002E
For more information visit: www.eatonelectrical.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SV9000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eaton SV9000

Summary of Contents for Eaton SV9000

  • Page 1 SV9000 AF Drives — Motor Pump Enhanced Protection Application Application Manual June 2004 Supersedes February 2001 MN04001002E For more information visit: www.eatonelectrical.com...
  • Page 2 Page ii (60) Motor Pump Enhanced Protection Application SV9000 Updates Update Note: Page 2 — Figure 3-1 — DIA3 (par. 2.2 = 10) becomes DIA2 (par. 11.1 = 10) Update Note: Page 17 — Addition to Code 12.1 Description —...

  • Page 3: Table Of Contents

    Page iii Manual Title SV9000 Motor Pump Enhanced Protection Application Contents General............2 Control I/O ........... 2 Control Signal Logic ........2 Parameter Group 0........3 4.1 Application Selection ......3 4.2 Parameter Loading ....... 3 4.3 Language ..........3 Basic Parameters, Group 1 ......
  • Page 4 Page iv (60) Motor Pump Enhanced Protection Application SV9000...

  • Page 5: General

    Page 1 (60) Motor Pump Enhanced Protection Application SV9000 1 General The Motor Pump Enhanced Protection The frequency reference, the analog and application is a modified version of the normal digital outputs have extra alternatives in their Multi-Purpose application. It has parameters for control parameters, however, the source of the torque control and for Fieldbus communication.

  • Page 6: Control Signal Logic

    Page 2 (60) Motor Pump Enhanced Protection Application SV9000 3 Control Signal Logic ARAMETERS 5 Reference selection 6 Jog speed ref. 10.1 Fieldbus control U in + PROGRAMMABLE PUSH BUTTON 2 Joystick control Internal U in + frequency reference Multi step I in ±...

  • Page 7: Parameter Group 0

    SV9000 Motor Pump Enhanced Protection Application Page 3 (60) 4 Parameter Group 0 Number Parameter Range Step Default Customer Description 0 = Motor Pump Enhanced Protection (loaded special application) 1 = Basic Application 2 = Standard Application Application 3 = Local/Remote...

  • Page 8: Basic Parameters, Group 1

    7 = I joystick control 8 = Signal from internal motor pot. 9 = Signal from internal motor pot. reset if SV9000 unit is stopped 10 = Signal from internal motor pot. (stored in memory over utility break) 11 = Min (V...

  • Page 9: Description Of Group 1 Parameters

    SV9000 Motor Pump Enhanced Protection Application Page 5 (60) 5.2 Description of Group 1 Parameters Minimum frequency Maximum frequency Defines frequency limits of the frequency converter. The default maximum value for parameters 1.1 and 1.2 is 120 Hz. By setting 1.2 = 120 Hz when the device is stopped (RUN indicator not lit) the maximum value of parameters 1.1 and 1.2 is changed to...
  • Page 10 Page 6 (60) Motor Pump Enhanced Protection Application SV9000 Analog input scaling, parameters 2.11—2.14 are not used when joystick control is used. (Par. 1.2) (Par. 1.2) (Par. 1.1) –10V –10V +10V +10V (Par. 1.1) Hysteresis ±2% (±0.2V) (Par. 1.2) (Par. 1.2) If minimum frequency (Par.
  • Page 11 SV9000 Motor Pump Enhanced Protection Application Page 7 (60) V/Hz ratio selection Linear: The voltage of the motor changes linearly with the frequency in the constant flux area from 0 Hz to the field weakening point (par. 6.3) where the nominal voltage is also supplied to the motor.
  • Page 12 Page 8 (60) Motor Pump Enhanced Protection Application SV9000 V/Hz optimization Automatic: The voltage to the motor changes automatically which makes the torque motor produce sufficient torque to start and run at low frequencies. The boost voltage increase depends on the motor type and power.

  • Page 13: Special Parameters, Groups 2-10

    SV9000 Motor Pump Enhanced Protection Application Page 9 (60) 6 Special parameters, Groups 2—10 6.1 Parameter tables Group 2, Input signal parameters Parameter Range Step Default Custom Description Page signal range 0—2 0 = 0—10 V 1 = Custom setting range 2 = -10—+10 V (can be used only...
  • Page 14 Page 10 (60) Motor Pump Enhanced Protection Application SV9000 Group 3, Output and supervision parameters Parameter Range Step Default Custom Description Page Analog output function 0—11 0 = Not used Scale 100% 1 = O/P frequency (0—f 2 = Motor speed (0—max.
  • Page 15 SV9000 Motor Pump Enhanced Protection Application Page 11 (60) Group 4, Drive Control Parameters Code Parameter Range Step Default Custom Description Page 0 = Linear Acc./Dec. ramp 1 shape 0—10 s 0.1 s >0 = S-curve acc./dec. time 0 = Linear Acc./Dec.
  • Page 16 Page 12 (60) Motor Pump Enhanced Protection Application SV9000 Group 5, Prohibit frequency parameters Code Parameter Range Step Default Custom Description Page Prohibit frequency range 0—f 0 Hz 1 low limit (1. 2) Prohibit frequency range 0—f 0 Hz 0 = Prohibit range 1 is off 1 high limit (1.
  • Page 17 SV9000 Motor Pump Enhanced Protection Application Page 13 (60) Group 7, Protections Code Parameter Range Step Default Custom Description Page 0 = No action Response to reference 1 = Warning 0—2 fault 2 = Fault, stop according to par 4.7...
  • Page 18 Page 14 (60) Motor Pump Enhanced Protection Application SV9000 Group 8, Autorestart parameters Code Parameter Range Step Default Custom Description Page Automatic restart: 0—10 0 = not in use number of tries Automatic restart: 1—6000 s 30 s trial time...
  • Page 19 SV9000 Motor Pump Enhanced Protection Application Page 15 (60) Group 10, Fieldbus Parameters Code Parameter Range Step Default Custom Description Page 0 = Control via I/O terminals 10.1 Fieldbus control select 0—1 1 = Control via Fieldbus board 10.2 MODBUS Slave address 1—247...
  • Page 20 Page 16 (60) Motor Pump Enhanced Protection Application SV9000 Group 11, Digital Input Parameters Code Parameter Range Step Default Custom Description Page 0 = Not Used 1 = Ext. Fault, Closing Contact 2 = External Fault, Opening Contact 3 = Run Enable 4 = Acc./Dec.
  • Page 21 Page 16A (60) Motor Pump Enhanced Protection Application SV9000 Group 11, Digital Input Parameters Code Parameter Range Step Default Custom Description Page 0 = Not used 1 = Ext. fault, closing contact 2 = External fault, opening contact 3 = Run enable 4 = Acc./dec.
  • Page 22 0 = Not used 1 = Ready 2 = Run 3 = Fault 4 = Fault inverted 5 = SV9000 overheat warning 6 = External fault or warning 7 = Reference fault or warning 8 = Warning 9 = Reversed...
  • Page 23 Page 18 (60) Motor Pump Enhanced Protection Application SV9000 Relay output RO2 12.12 0 – 600.0 s 0.1 s 0 = delay not in use off delay Relay output RO3 12.13 0 – 600.0 s 0.1 s 0 = delay not in use...

  • Page 24: Description Of Groups 2-10 Parameters

    SV9000 Motor Pump Enhanced Protection Application Page 19 (60) 6.2 Description of Groups 2-10 Parameters 6.2.1 Group 2, Analog Input Signal Parameters signal range 0 = Signal range 0—+10 V 1 = Custom setting range from custom minimum (par. 2.2) to custom maximum (par. 2.3) 2 = Signal range -10—+10 V , can be used only with Joystick control...
  • Page 25 Page 20 (60) Motor Pump Enhanced Protection Application SV9000 Analog input I custom setting minimum Analog input I custom setting maximum With these parameters, the scaling of the input current signal (I ) range can be set between 0—20 mA.
  • Page 26 SV9000 Motor Pump Enhanced Protection Application Page 21 (60) Scaled Scaled input signal (%) input signal (%) Par. 2.14 = 30% Par. 2.14 = – 30% Par. 2.15 = 80% Par. 2.15 = 140% 76.5 (15.3 mA) 17.7 (3.5 mA)
  • Page 27 Page 22 (60) Motor Pump Enhanced Protection Application SV9000 2 = Reducing DC brake current. The DC braking current can be reduced with the free analog input signal, between 0.15xI and current set with parameter 4.8. See figure 6.2-5. nSV9...
  • Page 28 SV9000 Motor Pump Enhanced Protection Application Page 23 (60) 4 = Reducing torque supervision limit. The set torque supervision limit can be reduced with the free analog input signal between 0 and set supervision limit (par. 3.11), see figure 6.2-7.
  • Page 29 Page 24 (60) Motor Pump Enhanced Protection Application SV9000 6.2.2 Group 3, Analog Output and supervision parameters Analog output function See table “Group 3, Output and supervision parameters”. Analog output filter time Filters the analog output signal. See figure 6.2-8.
  • Page 30 SV9000 Motor Pump Enhanced Protection Application Page 25 (60) Analog output minimum Defines the signal minimum to be either 0 mA or 4 mA (living zero). See figure 6.2-10. Analog output scale Scaling factor for analog output. See figure 6.2-10.
  • Page 31 Page 26 (60) Motor Pump Enhanced Protection Application SV9000 f(Hz) Par. 3.7 21 R01 21 R01 21 R01 22 R01 22 R01 22 R01 23 R01 23 R01 23 R01 Figure 6.2-11: Output Frequency Supervision 3.10 Torque limit supervision function...
  • Page 32 SV9000 Motor Pump Enhanced Protection Application Page 27 (60) 3.16 Frequency converter temperature limit supervision function 0 = No supervision 1 = Low limit supervision 2 = High limit supervision If the temperature of the frequency converter goes under/over the set limit (3.17) this function generates a warning message via the digital output DO1 or via the relay outputs RO1 or RO2 depending on the settings of the parameters 12.1—12.6.
  • Page 33 Page 28 (60) Motor Pump Enhanced Protection Application SV9000 6.2.3 Group 4, Drive Control Parameters Acc./Dec. ramp 1 shape Acc./Dec. ramp 2 shape The start and end of the acceleration and deceleration ramps can be smoothed with these parameters. Setting value 0 gives linear ramp shape, which causes acceleration and deceleration to act immediately to the changes in the reference signal with the time constant set by the parameter 1.3 and 1.4 (4.3 and 4.4).
  • Page 34 SV9000 Motor Pump Enhanced Protection Application Page 29 (60) Start function Ramp: The frequency converter starts from 0 Hz and accelerates to the set reference frequency within the set acceleration time. (Load inertia or starting friction may cause prolonged acceleration times).
  • Page 35 Page 30 (60) Motor Pump Enhanced Protection Application SV9000 (Hz) (Hz) Output frequency Motor speed Output frequency Motor speed DC braking On DC braking On t = 1 × Par. 4.9 t = 0.1 × Par. 4.9 Stop Stop Figure 6.2-14: DC-Braking Time when Stop = Coasting...
  • Page 36 SV9000 Motor Pump Enhanced Protection Application Page 31 (60) (Hz) Par. 4.11 Stop Figure 6.2-16: DC-Braking at Start 4.12 Multi-step speed reference 1 4.13 Multi-step speed reference 2 4.14 Multi-step speed reference 3 4.15 Multi-step speed reference 4 4.16 Multi-step speed reference 5 4.17...
  • Page 37 Page 32 (60) Motor Pump Enhanced Protection Application SV9000 6.2.4 Group 5, Prohibit Frequency Parameters Prohibit frequency range 1 low limit Prohibit frequency range 1 high limit Prohibit frequency range 2 low limit Prohibit frequency range 2 high limit Prohibit frequency range 3 low limit...
  • Page 38 SV9000 Motor Pump Enhanced Protection Application Page 33 (60) When the parameters 1.10 and 1.11, nominal voltage and nominal frequency of the motor, are set, parameters 6.3 and 6.4 are set automatically to the corresponding values. If different values for the field weakening point and the maximum output voltage are required, change these parameters after setting the parameters 1.10 and 1.11.
  • Page 39 Page 34 (60) Motor Pump Enhanced Protection Application SV9000 Response to external fault 0 = No response 1 = Warning 2 = Fault, stop mode after fault according to parameter 4.7 3 = Fault, stop mode after fault always by coasting A warning or a fault action and message is caused by the external fault signal in the digital input DIA3.
  • Page 40 7.5-7.9 General The motor thermal protection is to protect the motor from overheating. The SV9000 drive is capable of supplying higher than nominal current to the motor. If the load requires this high current there is a risk that motor will be thermally overloaded. This is true especially at low frequencies.
  • Page 41 Page 36 (60) Motor Pump Enhanced Protection Application SV9000 Setting this parameter (or parameter 1.13) does not affect the maximum output current of the drive. Parameter 1.7 alone determines the maximum output current of the drive. Current limit Par. 1.7 Overload area Par.
  • Page 42 SV9000 Motor Pump Enhanced Protection Application Page 37 (60) Motor thermal protection break point frequency The frequency can be set between 10—500 Hz. This is the breakpoint of thermal current curve. With frequencies above this point the thermal capacity of the motor is assumed to be constant. See figure 6.2-20.
  • Page 43 Page 38 (60) Motor Pump Enhanced Protection Application SV9000 Parameters 7. 10— 7. 13, Stall protection General Motor stall protection protects the motor from short time overload situations like a stalled shaft. The reaction time of stall protection can be set shorter than with motor thermal protection.
  • Page 44 SV9000 Motor Pump Enhanced Protection Application Page 39 (60) 7.12 Stall time The time can be set between 2.0—120 s. This is the maximum allowed time for a stall stage. There is an internal up/down counter to count the stall time. See figure 6.2-22. If the stall time counter value goes above this limit the protection will cause a trip (see parameter 7.10).
  • Page 45 Page 40 (60) Motor Pump Enhanced Protection Application SV9000 7.15 Underload prot., field weakening area load Operation: 0 = Not in use 1 = Warning 2 = Fault Tripping and warning will display the same message code. If tripping is set active the drive will stop and activate the fault stage.
  • Page 46 SV9000 Motor Pump Enhanced Protection Application Page 41 (60) Underload time counter Trip area Par. 7.17 Trip/Warning Par. 7.14 Time Underload No Underload Figure 6.2-24: Counting the Underload Time. 7.18 Phase supervision of the supply voltage 0 = No action...
  • Page 47 Page 42 (60) Motor Pump Enhanced Protection Application SV9000 6.2.7 Group 8, Autorestart Parameters Automatic restart: number of tries Automatic restart: trial time The Automatic restart function restarts the frequency converter after the faults selected with parameters 8.4—8.8. The Start function for Automatic restart is selected with parameter 8.3.
  • Page 48 SV9000 Motor Pump Enhanced Protection Application Page 43 (60) Number of faults Par. 8.2 = 3 during t = t trial Par. 8.1 = t trial trial trial Three Faults Four Faults Stop Figure 6.2-25: Automatic restart...
  • Page 49 Page 44 (60) Motor Pump Enhanced Protection Application SV9000 6.2.8 Group 9, Torque Control Torque Control Torque control can be activated either by setting parameter 6.1 to torque control or with digital input DIA3 (parameter 2.2=10). The torque reference source is selected with parameter 9.1 and reference scaling with parameters 9.2 and 9.3.
  • Page 50 SV9000 Motor Pump Enhanced Protection Application Page 45 (60) 6.2.9 Group 10, Fieldbus Parameters Fieldbus control Fieldbus control can be activated with parameter 10.1. Then the frequency or speed reference comes from the fieldbus as well as the Start/Stop and Reverse control.
  • Page 51 Page 46 (60) Motor Pump Enhanced Protection Application SV9000 10.7 Profibus baud rate 9.6 kbaud 19.2 kbaud 93.75 kbaud 187.5 kbaud 500 kbaud 1.5 Mbaud 3 Mbaud 6 Mbaud 12 Mbaud 10: AUTO (Automatic baud rate select) 10.8 Profibus PPO Type Selection of Profibus PPO type.
  • Page 52 SV9000 Motor Pump Enhanced Protection Application Page 47 (60) 6.2.10 Group 11, Digital Input Parameters 11.1 DIA2 function External fault, closing contact = Fault is shown and motor is stopped when the input is active. External fault, opening contact = Fault is shown and motor is stopped when the input is not active.
  • Page 53 Page 48 (60) Motor Pump Enhanced Protection Application SV9000 Output frequency Par. 4.10 DIA3 Stop a) DIA3 as DC-brake command and stop mode = Ramp Output frequency DIA3 Stop b) DIA3 as DC-brake command input and stop mode = Coasting Figure 6.2-26: DIA3 as DC-Brake Command Input: a) Stop-Mode = Ramp, b) Stop-Mode = Coasting...
  • Page 54 SV9000 Motor Pump Enhanced Protection Application Page 49 (60) 11.4 DIB6 function (terminal 16) Selections are the same as 11.3 except: 10: Motorized Pot. Down = 11.5 DIC1 function (Refer to page 16) Selections are the same as 11.1 except: 10: Multi-Step 1 contact closed = Selection 1 active (speed select 1) 11: Internal Motor Speed Pot.
  • Page 55 3 = Fault A fault trip has occurred 4 = Fault inverted A fault trip has not occurred 5 = SV9000 overheat warning The heat-sink temperature exceeds +70 6 = External fault or warning Fault or warning depending on parameter 7.2 7 = Reference fault or warning Fault or warning depending on parameter 7.1 -...
  • Page 56 SV9000 Motor Pump Enhanced Protection Application Page 51 (60) 12.7 Digital output DO1 on delay 12.8 Digital output DO1 off delay 12.9 Relay output RO1 on delay 12.10 Relay output RO1 off delay 12.11 Relay output RO2 on delay 12.12 Relay output RO2 off delay 12.13...

  • Page 57: Fault Code

    Page 52 (60) Motor Pump Enhanced Protection Application SV9000 7 Fault Code The Motor Pump Enhanced Protection application has some extra fault codes: Fault Number Fault Possible Cause Check Fieldbus Fieldbus board has detected the reset of Reset the fault and restart...

  • Page 58: Sv9Ioc103 Control Connections

    SV9000 Motor Pump Enhanced Protection Application Page 53 (60) 9 SV9IOC103 Control Connections Terminal Signal Description +24V Control voltage output Voltage for switches, etc. max 50 mA I/O ground Ground for reference and controls Common for DIC1—DIC5 Connect to GND or +24V Programmable;...
