Dual Sided - Steelcase Migration SE Boundary Screen Quick Start Manual

®

Dual Sided

For Dual-sided Benches
1) Assemble the mounting bracket using (3) M6
buttonhead thread forming screws (provided).
Attach the mounting bracket to underside of the cross-tube
weldment.
TIP: Bracket is centered on dual sided applications
2a) Use a level to check the vertical orientation. 2b) Loosen
(6) buttonhead screws using a 5/32" allen wrench, 2c) Adjust
the interface bracket to vertical and
2d) Retighten (6) buttonhead screws.
.472"
(12mm)
1
3x
5/32"
2b
2a
2d
2c
Page 2 of 5
149905 Rev A
