CMSIS PACK IN KEIL μVISION5
After the Keil μVision5 IDE is installed, open the application
and use the following steps to properly set up the
device from the IDE:
1. Open the CMSIS pack installer as shown in Figure 6.
When the pack installer is opened for the first time, it may
take a few minutes to update the pack installer.
Figure 6. Pack Installer
2.
ADuCM420
3.
Figure 7. Pack Installer
Figure 8. ADuCM420 Device in Keil μVision5
Rev. 0 | Page 8 of 20
EVAL-ADUCM420QSP1Z
After the CMSIS pack installer opens, click File > Import.
Select and import the ADuCM420 pack that is included in
the installation setup (see Figure 7).
With the ADuCM420 CMSIS pack installed, the
ADuCM420 device is supported by the Keil μVision5 IDE.
The ADuCM420 appears in the Device tab of the Keil
window, as shown in Figure 8.
